Chapter 5 Specification
1. System
Host Interface PCI
Operating Voltage
5VDC ± 5%
2. RF Performance
802.11g(BACKWARD COMPATIBLE TO 802.11b)
Frequency Bands 2412-2484 MHz (subject to local regulations)
Modulation Technology OFDM and DSSS
Modulation Techniques 64QAM, 16QAM, QPSK, BPSK, CCK, DQPSK, DBPSK
Date Rates 54, 48, 36, 18,12, 9, 11, 6, 5.5, 2, and 1 Mbps, auto fallback
Typical Power Consumption Receive: 240 mA
Transmit: 400 mA
Peak Output Power 20 dBm @ Nominal Temp Range
Receive sensitivity -70dBm @54Mbps; -87dBm@11Mbps
Antenna External antenna with the gain of 2dBi
3.Safety Regulation and Operating Environment
FCC Part 15 (USA) DGT (Taiwan)
EMC certification
CE (Europe)
Temperature Range Operating: 0 ~ 55 deg C, Storing: -20 ~ 65 deg C
Humidity Max. 90% Non-condensing
4. Software Support
Driver Windows 98SE/Me/2000/XP
Security
WPA-PSK(TKIP,AES); 802.1X client for Windows XP
,64/128 bit WEP
Roaming Seamless roaming among 802.11b/g access points.
Management Utility Monitors the network situation.
5. Mechanical
Dimensions 134mm*121mm*22mm (134mm*81mm*22mm)
Weight 55.5(51.5)± 1 g
Packaging Packaging specially used by Gigabyte.
LED indicators Act and Link
*This specification is subject to change without notice.
