Item Brochure

The EZ-Grade 360 is a versatile, construction-tough laser receiver
that can be mounted on dozers, motor graders, motorized scrapers,
skid-steer loaders, backhoes and excavators. The built-in super bright
display and battery pack make the EZ-Grade 360 ideally suited for
visual machine control applications.
Construction Tough
The integral molded rubber housing components provide maximum protection from
shock, water, and dust. All of the controls and plugs are recessed for protection. The
EZ-Grade 360 is the choice of the professional contractor.
SPECIFICATIONS
Reception………....……………………………….360°
Capture Height………………………….....8” (203mm)
Channels………………………………..…..…………7
Batteries 4 D cell……………………..Alkaline (40 hrs)
Power Options………………………....NiCad (20 hrs);
12/24V DC power cord
Laser Type………………………….Visible or infrared
Body.…………………………………. Shock resistant
Window…………………………………Polycarbonate
Control…………………………….…....Bright/off/dim
Clamp Capacity……...1” (2.54cm) to 2” (5.08cm) O.D.
Accuracy…………………………….…..±1/8” (±4mm)
Size……..12” x 6-1/4” x 8-1/2” (30.5 x 15.8 x 21.6 cm)
Weight……………………………………7 lbs. (3.2kg)
Display & Automatic Control
Options
If you need an in-cab display or automatic system,
there are three options to choose from, starting with
the simple 322 manual display with three lights. Or
you can contact your authorized AGL Machine
Control Dealer and upgrade to automatic control using
the 312 system with one-button operation or the 304
Automatic Survey system. This system also offers the
capability to be connected to a laptop or data collector
for survey points.
Greater Information
The EZ-Grade’s 8” capture height, 360° reception, and 7-channel super-bright display
provide the operator with the information needed to get the job ON-GRADE!
EZ-Grade 360
™
Mounting
The receiver’s
dual clamping
method is
simple, reliable
and versatile. It
will mount
easily to any
pipe or tube
with an outside
diameter of one
to two inches.
Specifications subject to change without notice.
AM1110 Printed in USA 1/2007
2202 Redmond Rd., Jacksonville, AR 72076
[e-mail]  www.agl-lasers.com
Toll Free: 800.643.9696  Fax: [phone]
322
312
304
