- GENICOM LLC User Guide printer LN45, mL450
Table Of Contents
- How This Manual is Organized
- Preface
- Unpacking and Installing Your Printer
- About this Chapter
- Installation Precautions
- Unpacking the Printer
- Installing the EP Cartridge
- Adding paper to the 500-sheet universal paper cassette
- Connecting the Parallel Cable
- Connecting the Ethernet Cable
- Connecting the Power Cord
- Turning the Printer On
- Selecting a Display Language
- Installing Printer Drivers
- Printing a Configuration Summary
- Printing a Test Page
- Printing PCL and PostScript Font Lists
- Turning the Printer Off
- Printer and Options Parts and Functions
- Understanding Paper, Paper Paths, Paper Delivery and Paper Loading
- About this Chapter
- Paper
- Paper Size Requirements
- Media Sizes Supported
- Media Types supported
- Paper Orientation
- Long and Short Edge Duplex Binding in Portrait and Landscape Orientations
- Paper Paths
- Paper Delivery
- Adding paper to the 500-sheet paper cassette, Tray 1 or Tray 2
- Adding paper to the multi bypass feeder
- Adding paper to the HCF unit (2500-sheet)
- Loading envelopes into the envelope feeder
- Understanding and Navigating the Control Panel Menus
- Printer Consumables, Cleaning and Maintenance
- Troubleshooting
- About this Chapter
- Solving Printer Power-on Problems
- Solving Print Quality Problems
- Clearing Paper Jams
- Clearing Paper Jams from Area A
- Clearing Paper Jams from Area B
- Clearing Paper Jams from Area C
- Clearing Paper Jams from Area E
- Clearing Paper Jams from Area F
- Clearing Paper Jams from Area H
- Clearing Paper Jams from Tray 1
- Clearing Paper Jams from Tray 2
- Clearing Paper Jams from Trays 3, 4 and 5 in the HCF unit
- Clearing Paper Jams from the Multi-Bypass Feeder (MBF)
- Clearing Paper Jams from the Envelope Feeder
- Control Panel LCD Messages
- Ethernet Network Interface Troubleshooting
- Using DRAM DIMMs, FLASH DIMMs and Power-on Files
- General Information
- Safety Notes and Regulatory Compliances
- Printing Font Summaries
- Frequently Used Ethernet Commands
- GENICOM Customer Support and Part Numbers
Publication No. GEG-99126 Genicom Aug 01
4-6 GENICOM LN45 and Intelliprint mL450 User Guide
Menu Structure
Menu Structure
The following figure shows the structure of the control panel main menus and submenus.
Figure 5-3: Printer Menu Structure.
Paper Menu
Copies
Default Source
Manual Feed
Output Tray
Media Size/Type
MBF
Tray 1
Tray 2
Tray 3 (optional)
Tray 4 (optional)
Tray 5 (optional)
Tray Linking
Job Offset
Blank Pages
Face Up Inst
MBF First
Interface Menu
Port
Parallel
Network 1
Parallel Setup
Interpreter
Format
Mode
Network 1Setup
Interpreter
Format
Network Channel
Network Address
IP Address
Subnet Mask
Default Router
LPD Banner
DHCP
Network Frame
Delay Out Close
PS Menu
Print PS Errors
Manual Feed TO
PCL Menu
Orientation
Font Source
Font Number
Pitch
Symbol Set
Macro Filter
Lines Per Page
CR Mode
LF Mode
FF Mode
Print Area
Parameter Values
Paper Source
Paper Size
System Menu
Factory Defaults
Display Language
Alarm Control
Power Saver
Standby Time
Wait Timeout
Job Timeout
Jam Recovery
Hex Print
Toner Out
Quality Menu
Resolution
Enhancement
Toner Saver
Print Density
Functions
Reset Printer
Print Summary
Print Test
Print Fonts
Status Menu
MBF
Media Size
Media Type
Level
Tray 1
Media Size
Media Type
Level
Tray 2
Media Size
Media Type
Level
Tray 3 (optional)
Media Size
Media Type
Level
Tray 4 (optional)
Media Size
Media Type
Level
Tray 5 (optional)
Media Size
Media Type
Level
Face Down Tray
Toner
