3-4 GENICOM LN45 and Intelliprint mL450 User Guide
Media Sizes Supported
NOTE: 1. Different size papers cannot be mixed and loaded into the same paper source.
2. Duplex printing is possible only when the optional duplexer is installed.
Media Sizes Supported
NOTE: In the following table, SEF refers to Short Edge Feed whereas LEF refers to Long Edge Feed.
See “Paper Orientation” on page 3-6
.
Tray 4
Tray 5
A4 LEF 210 297 Yes Yes
8.5” x 11” LEF 216 280 Yes Yes
7.5” x 10.5” LEF 330 216 Yes Yes
B5 LEF 182 257 Yes Yes
Paper
Source
Paper Size Simplex
Printing
Duplex
Printing
MEDIA SIZE Tray
1
Tray
2
Tray
3
Tray
4
Tray
5
MBF Env
Fdr
LEDGER (11” x 17”) * * * *
LETTER LEF (8.5” x 11”) * * * ***
LEGAL (8.5” X 14”) * * * *
FOLIO (8.5” X 13”) * * * *
EXECUTIVE (7.25” X 10.5”) * * * ***
STATEMENT (5.5” X 8.5”) * *
A3 *** *
A4 LEF ******
A4 SEF *
A5 * *
A6 *
B4 *** *
B5 ******
MONARCH ENVELOPE * *
DL ENVELOPE * *
C5 ENVELOPE * *
