Aug 01 Genicom Publication No. GEG-99126
GENICOM LN45 and Intelliprint mL450 User Guide 2-3
Rear View
NOTE: The upper left cover can be closed only when the EP cartridge is installed in the printer. Do not
close it when the EP cartridge is not inside the printer.
Rear View
Operation Panel
Display
Shows error messages and other status information. Refer to ”Chapter 4 Understanding and Navigating the
Control Panel Menus” for a detailed discussion about using the LCD display and push-buttons of the control
panel.
1 DUPLEXER connector Connects to the optional duplexer.
2 OUTPUT connector Connects to the optional Finisher/Stapler unit.
3 TRAY connector Connects to the optional HCF (High Capacity Feeder)
unit.
4 Power cord receptacle Connects to an AC outlet.
5 AC outlet Supplies power to the optional Finisher/Stapler unit.
6 Controller Houses the parallel and RJ45 ports and optional
network interfaces.
