User's Manual

General Dynamics Itronix 72-0139-001
GD2000 User Guide
Customizing the BIOS
The Advanced Menu
The Advanced Menu provides the user with the ability to
configrure specific system settings.
Field Setting Function
Stealth Mode Configuration Sub-Menu Depending on Stealth Mode setting, LED, FAN Beeps, LCD Bright-
ness, Audio and Wireless devices will keep silent when activated.
This allows the computer to be used in an environment where
sound and light could be dangerous or disruptive.
Keyboard Features Sub-Menu Selects keyboard options such as NumLock power on state, Light
Sensor, Backlight, and left button.
Graphics Memory Sub-Menu Sub-Menu Select the amount of total graphics memory
USB Control Sub-Menu Sub-Menu Enable/Disable all external USB ports
Super IO Configuration Sub-Menu Configure I/O Devices (serial ports) on the vehicle dock, office
dock and the GPS radio
2nd Super IO Configuration Sub-Menu Configure I/O Devices (serial ports) on the Expansion Module
(Only displayed if Expansion Module is installed)
Battery Calibration Sub-Menu Sub-Menu Configure Virtualization and system resumption
SATA Mode
IDE
AHCI
Controls the mode in which the SATA controller should operate.
Intel Execution-Disable Bit
ENABLED
Disabled
When disabled, forces the Execute-Disable Bit Capability
extended feature bit to always return to 0.
System Cooling Mode Cool
NORMAL
Max Performance
Set cooling mode.
Cool: CPU is slowed down to reduce heating
Normal: CPU runs normally
Max Performance: CPU runs as fast as necessary
NOTE Max Performance will not allow the unit to over-heat.
However, over-heating will limit performance and the fan will run.
Resume on Modem Ring
OFF
On
The system wakes from sleep when an incoming call is detected if
the setting is On.
WLAN Support
ENABLED
Disabled
The WLAN device is powered on when the system boots if the
WLAN support is enabled. It is not powered on when the system
boots if the WLAN support option is disabled.
Bluetooth
®
Support
ENABLED
Disabled
The Bluetooth
®
device is powered on when the system boots if
the Bluetooth
®
support is enabled. It is not powered on when the
system boots if the Bluetooth
®
support option is disabled.
