User's Manual

General Dynamics Itronix 72-0139-001
GD2000 User Guide
Getting Familiar
Function Keys and Key Combinations
When using function keys, press and hold one of the FN
keys, then press the other key in the key combination.
Function
Key
Function Description
FN+F1 Help Opens the Microsoft Help and Support Center.
FN+F2 to
F12
Application Specific
Functions
Selects functions within software applications. Refer to application help for informa-
tion about function key combinations.
FN+BKSP Break Use FN+BKSP as you would use the BREAK key on any PC.
FN+P Print Screen Prints the current screen.
FN+P+ALT Print Window Prints the current active window.
FN+ESC Pause Pauses and resumes an application. Press once to pause. Press again to resume.
FN+ Q Audio Volume Up Increases the audio volume
FN+ A Audio Volume
Down
Decreases the audio volume
FN+R Radio on/off Turns all wireless functions on/off (option with any radios).
FN+SHIFT Caps Lock Locks/unlocks keys A through Z in the UPPER CASE position. Press once to lock.
Press again to return the letters to lower case. While in the upper case mode, press
the
SHIFT key for lowercase characters. You still have to use the SHIFT key to display
characters located on the upper portion of the keyboard. For example, press
SHIFT+8
to type an asterisk (*), even when the
CAPS LOCK key is activate.
The Caps Lock LED
lights when the keyboard is in Caps Lock mode.
FN+INSERT/
DEL
Insert Inserts text in documents and applications.
Function Keys
