Integration Instructions

P1D Broadband Module Integration
21 March 2001 Proprietary Information Page 9 of 11
15 Serial CTS
16 Serial TXD
17 DTE Ground
18 Chassis Ground
G1, G2 Chassis Ground
Table 1: 18 way Data Connector
3.3 DC Power Input J1
The module requires a DC supply of 5VDC at upto 1A, the input voltage is required to be with ±5% of
nominal voltage. The connector type is a standard DC plug for 0.65mm centre pin configured as
centre positive.
3.4 Battery Contact J3
The module provides board contacts to allow an external battery pack to be used, connection to these
contact is made using spring fingers. The recommended battery is a lithium ion pack nominal voltage
3.7VDC, capacity 650mAh.
3.5 SIM Holder Socket 2
The IPWireless P1D Broadband module supports SIM authentication if required.
