Technical Specifications

1 of 2

Service and non-Service rated Smart Switches

Automatic Transfer Switches

with Digital Power Management Technology

Smart Switches

Smart

Switches

100 - 400 Amps, Single Phase

DESCRIPTION

Generac Smart Switches are designed for use with single phase generators that utilize an Evolution™ Controller. The 100, 200,

and 400 amp open transition switches are available in single phase in both service equipment rated and non-service equipment

rated configurations. The 150 and 300 amp open transition switches are only available in a service rated equipment configuration.

STANDARD FEATURES

100-200 amp Generac Smart Switches are housed in an aluminum NEMA/UL Type 3R enclosure*, with electrostatically applied

and baked powder paint. The Heavy Duty Generac Contactor is a UL recognized device, designed for years of service. The

controller at the generator handles all the timing, sensing, exercising functions, and transfer commands. Smart switches are

covered by a 5 year limited warranty.

* 300 & 400 amp switches are housed in a steel enclosure.

DPM TECHNOLOGY

Through the use of Digital Power Management technology (DPM), each of these switches has the capability to truly manage two

air conditioning loads with no additional hardware. When used in tandem with the Power Management Module (PMM) starter kit,

individual PMMs can be use to intelligently manage up to four more additional loads.

*CUL only applies to non-service rated switches

PAGE 1
Smart Switches Service and non-Service rated Smart Switches Automatic Transfer Switches with Digital Power Management Technology Smart Switches ® 1 of 2 100 - 400 Amps, Single Phase *CUL only applies to non-service rated switches DESCRIPTION Generac Smart Switches are designed for use with single phase generators that utilize an Evolution™ Controller.
PAGE 2
Smart Switches ® 2 of 2 100-400 Amps, Single Phase Smart Switches Functions All timing and sensing functions originate in the generator controller Utility voltage drop-out.......................................................................................................................................................................................................................<60% Timer to generator start............................................................................................
