MLT6SMD
ENGINE
• Mitsubishi® L3E – liquid cooled, diesel engine
o Standby - 12.2 hp @ 1800 rpm
o Prime - 10.5 hp @ 1800 rpm
o 1.0 L displacement, 3 cylinder
o ECOSpeed™ EPA Final Tier 4 compliant multi-speed operation
• Polyethylene Fuel Tank:
o Fuel Type: Diesel
o Fuel Capacity: 39.9 gal (151.04 L)
o External 3.5 in. (89 mm) fill port
• Fuel Consumption:
o Lights Only: 0.195 gph (0.738 Lph)*
o Full Load: 0.549 gph (2.078 Lph)*
o Maximum Runtime (Lights Only): 205* hours
• Cooling system allows operation to 120°F (49⁰C) ambient
• 750-hour** service interval
• Full flow oil filter, spin on type
• Dry type cartridge air filter
• Wind Rating: 65 mph (105 kph)
*Results based on engine manufacturer and field test data after 100-hour engine break-in period and may vary based on factors including age
and maintenance of equipment, environmental conditions and fuel density. Consult the Owner's Manual for fuel and maintenance
recommendations.
**To achieve maximum service interval, replacement of oil filter after 50-hour break-in period is required. Consult Owner’s Manual for required
oil filter model number.
GENERATOR
• Marathon Electric® ,Brushless
• Output:
o Up to 6kW standby
o Up to 5kW (lights on)
• 120/240 VAC – 50/25A
• +/-1% automatic voltage regulation
ELECTRICAL CONTROLS
• Power Zone Autolight Controller
• Automated dusk to dawn or 7-day scheduler operation
• One touch manual starting
• Individual light fixture control
• Back-lit LCD display -40ºF/C rated heated display.
• Three (3) programmable service timers for Fuel Filter, Air Filter and Oil Service
• Alarms and comprehensive warnings
• Electrical trip or shutdown protection upon fault condition
• Key pad controlled electric mast optioned deployment
SPECIFICATIONS
MOBILE LED LIGHT TOWER
