Replacement Part List
Easier than ever before!
HOMELINK MANUAL TRANSFER SWITCH KITS
Temporary Home Backup Power Solutions. Generac’s HomeLink
Upgradeable Manual Transfer Switches are now easier to install, expand
and maintain than ever before. Compatible with the requirements of 2017
National Electric Codes, the improved 30-amp and 50-amp
HomeLink models can be used with any portable
generator featuring GFCI outlets.
With interchangeable circuit breakers that simplify
the reconguration process required for replacing
or expanding from 8 to 16 circuits, HomeLink switches
can be used to provide power to hard-wired loads such as your home’s furnace, well pump or
lights. Unlike other manual transfer switches available to the general public, HomeLink models can
also be upgraded for automatic functionality with Generac home standby generators up to 11 kW
by simply changing out the original controller assembly.
Power Inlet Boxes
AMPS ENCLOSURE TYPE MODEL NUMBER
30 AMP
Raintight Aluminum 6343
Raintight Resin 6337
Raintight Resin with flip lid 6340
Aluminum with flip lid 6346
50 AMP
Raintight Aluminum 6344
Raintight Resin 6338
Raintight Resin with flip lid 6341
Aluminum with flip lid 6347
AMPS LENGTH (FT) GAUGE/WIRE PLUG/CONNECTOR MODEL NUMBER
15 AMP 50 14/3 5-15 Plug & (4) 5-15 Connectors 6883
30 AMP
10 10/4 L14-30 Plug & Connector 6327
20 10/4 L14-30 Plug & (4) 5-20R Connectors 6112
25 10/4 L14-30 Plug & Connector 6328
50 10/4 L14-30 Plug & Connector 6329
50 AMP
10 6/4 14-50 Plug & CS6364 Connector 6330
25 6/4 14-50 Plug & CS6364 Connector 6389
50 6/4 14-50 Plug & CS6364 Connector 6390
Power Cords
POWER INLET BOXES
POWER CORDS
Designed for use with manual transfer switches and power inlet boxes, Generac’s heavy duty, all rubber
power cords connect your generator to the power inlet box and/or transfer switch. The plug and connector
match up with the power inlet on each transfer switch and power inlet box. Most portable generators are
supplied with a locking receptacle that accepts the
locking plug on one end of the power cord.
• 30 Amp, 10 gauge – 4 wire – L14-30 plug & connector
• 30 Amp, 10 gauge – 4 wire – L14-30 plug & (4) 5-20 receptacles
• 50 Amp, 6 gauge – 4 wire – 14-50 plug & CS6364 connector
• Lengths ranging from 10 feet to 50 feet
• UL
®
listed
Aluminum
with Flip Lid
Raintight Resin
Raintight Aluminum
A power-inlet box is used to connect a portable generator to an indoor transfer switch. It mounts on the
exterior of the house or building, and is wired to the transfer switch allowing the portable generator cord
to be plugged into the power-inlet box.
• Aluminum and resin enclosures available (standard or raintight)
• A variety of 30 Amp and 50 Amp models
Power Inlet Box Accessory
Spring-loaded ip lid for power inlet box
(must be mounted prior to installation).
30 AMP Generator
Power Cord
30 AMP Multi-Outlet
Generator Power Cord
50 AMP Generator
Power Cord
AMPS PORTABLE GENERATOR WATTS
MANUAL TRANSFER
SWITCH KIT
TRANSFER
SWITCH
POWER
INLET BOX
POWER CORD
GP1800, iQ2000, GP2200 N/A 6375 N/A 6883
3250 - 4000 Watts
Generac Models:
GP3250, GP3300, LP3250, XG4000, XP4000
6853 (Must use custom cord to con-
nect from generator to Power Inlet Box)
6854(Must use custom cord to connect
from generator to Power Inlet Box)
6333
6377
6382
Buy Locally N/A
5500 - 10000 Watts
Generac Models: GP5500, RS5500, XD5000E,
GP6500, GP6500E, XC6500, XC6500E, RS7000E,
GP7500E, GP8000E, XT8000E, XC8000E
6853
6854
6852
6333
6377
6382
6337
6340
6343
6346
6327
6328
6329
6112
10000 - 17500 Watts*
Generac Models:
XG10000, XP10000, GP15000, GP17500
9855
9854
6333
6334
6335
6338
6341
6344
6347
6330
6389
6390
Compatibility Chart
5-15
NEMA 3R
Outlet Congurations
L5-20
L5-20
4x
CHARGER
12V DC
30 AMP RV
5-15
NEMA 3R
5-15
NEMA 3R
L5-20
5-15
NEMA 3R
Outlet Congurations
L5-20
L5-20
4x
CHARGER
12V DC
30 AMP RV
5-15
NEMA 3R
5-15
NEMA 3R
L5-20
5-15
NEMA 3R
Outlet Congurations
L5-20
L5-20
4x
CHARGER
12V DC
30 AMP RV
5-15
NEMA 3R
5-15
NEMA 3R
L5-20
5-15
NEMA 3R
Outlet Congurations
L5-20
L5-20
4x
CHARGER
12V DC
30 AMP RV
5-15
NEMA 3R
5-15
NEMA 3R
L5-20
Homelink Manual Transfer Switches
AMPS
MODEL
NUMBER
ENCLOSURE
Flush or
Surface Mount
CIRCUITS
PROVIDED
INCLUDED BREAKERS KIT INCLUDES
For over 57 years, Generac has
led the market in reliable backup
power solutions for consumers,
and businesses.
Pre-wired for easy installation, these updated switch models also feature an electronic rocker button that
seamlessly switches between utility and generator power. Indicator lights identify the presence of utility and/or
generator power, and bundled options are currently available with cords and power inlet boxes included. Thanks
to the re-launch of Generac’s HomeLink Upgradeable Manual Transfer Switches, protecting your desired loads
and transitioning from portable power to an automatic standby solution is easier than ever before.
Raintight Resin with Flipi Lid
• 30 Amp Kit protects 8 circuits, and accepts interchangeable breakers to expand up to 10 circuits
(including Arc-Fault and GFCI). For use with portable generators equipped with a L14-30 outlet.
• 50 Amp Kit protects 10 circuits, and accepts interchangeable breakers to expand up to 16 circuits
(including Arc-Fault and GFCI). For use with portable generators equipped with a 14-50 outlet.
INSTALL NOW FOR
THE PORTABLE
GENERATOR
UPGRADE LATER TO
THE HOME STANDBY
GENERATOR
50 Amp
50 Amp
30 Amp
30 Amp
30 Amp
9855
9854
6854
6853
6852
Indoor
(NEMA 1)
Indoor
(NEMA 1)
Indoor
(NEMA 1)
Indoor
(NEMA 1)
Indoor
(NEMA 1)
10
10
8
8
8
(1) 30 Amp 2-pole
(1) 20 Amp 2-pole
(2) 20 Amp 1-pole
(2) 20 Amp 1-pole tandem
(1) 30 Amp 2-pole
(1) 20 Amp 2-pole
(2) 20 Amp 1-pole
(2) 20 Amp 1-pole tandem
1- 30 Amp 2- pole
1- 20 Amp 1- pole
5- 15 Amp 1- pole
1- 30 Amp 2- pole
1- 20 Amp 1- pole
5- 15 Amp 1- pole
1- 30 Amp 2- pole
1- 20 Amp 1- pole
5- 15 Amp 1- pole
Transfer Switch.
Cord: 10’ 6/4 with CS6365 female and 14-50 male ends
Power inlet Box: 50 Amp aluminum (must be hardwired)Install manual,
wiring, harness, conduit and fittings
Transfer Switch.
Install manual, wiring harness, conduit & fittings.
Transfer Switch.
Cord: 10’ 10/4 with L14–30 ends.
Power inlet Box: 30 Amp aluminum (must be hardwired) Install manual, wiring harness,
conduit & fittings.
Transfer Switch.
Cord: 10' 10/4 with L14–30 ends.
Power inlet Box: 30 Amp resin (must be hardwired) Install manual, wiring harness, conduit & fittings.
Transfer Switch.
Install manual, wiring harness, conduit & fittings.
Miscellaneous
MODEL NUMBER
Storage Cover for iQ2000 6875
Storage Cover for 5-8kW portables 6811
iQ2000 Parallel Kit 6877
GP2200i Parallel Kit 7118
XD Portability Kit 6910
iQ2000 Inverter Generators
using the iQ2000 Parallel Kit
