Specification Sheet

COMMERCIAL 30 kW
KW RATING 30 LP / 29 NG
ENGINE SIZE 1.6 Liter 4 cyl. inline
GENERATOR OUTPUT VOLTAGE/KW - 60Hz KW AMP CB Size
120/208V, three phase, 0.8 pf 30 LP / 29 NG 104.2 LP / 100.7 NG 125
120/240V, three phase, 0.8 pf 30 LP / 29 NG 90.3 LP / 87.3 NG 100
277/480V, three phase, 0.8 pf 30 LP / 29 NG 45.1 LP / 43.6 NG 50
GENERATOR LOCKED ROTOR KVA
AVAILABLE @ VOLTAGE DIP OF 35%
208 or 240V three phase 56
480V three phase 62
ENGINE FUEL CONSUMPTION
(Natural Gas) (Propane) Natural Gas Propane
(ft
3
/hr.) (gal/hr.) cu ft/hr
Exercise cycle 60 0.65 24
25% of rated load 193 2.1 76
50% of rated load 300 3.3 120
75% of rated load 415 4.5 165
100% of rated load 525 5.7 209
ENGINE COOLING
Air flow
(inlet air including alternator and combustion air) ft
3
/min. 1,800
System coolant capacity US gal. 2.0
Heat rejection to coolant BTU/hr. 131,000
Max. operating air temp. on radiator °C (°F) 60 (150)
Max. ambient temperature °C (°F) 50 (140)
COMBUSTION AIR REQUIREMENTS
Flow at rated power 60 Hz cfm 95
SOUND EMISSIONS IN DBA
db(A) @ 23 feet in exercise mode 62
db(A) @ 23 feet at normal operating load 75
EXHAUST
Exhaust flow at rated output 60 Hz cfm 260
Exhaust temp. at muffler outlet °F 1025
ENGINE PARAMETERS
Rated synchronous RPM 60 Hz 3600
HP at rated KW 60 Hz 48
POWER ADJUSTMENT FOR AMBIENT CONDITIONS
Temperature Deration 3% for every 10 °C above - °C 25
1.65% for every 10 °F above - °F 77
Altitude Deration 1% for every 100 m above - m 183
3% for every 1000 ft. above - ft. 600
OPERATING DATA
COMMERCIAL 30 kW
RATING: All three phases units are rated at 0.8 power factor. All single phase units are rated at 1.0 power factor. STANDBY RATING: Standby ratings apply to installations served by a
reliable utility source. The standby rating is applicable to varying loads for the duration of a power outage. There is no overload capability for this rating. Ratings are in accordance
with ISO-3046-1. Design and specifications are subject to change without notice. Maximum wattage and current are subject to and limited by such factors as fuel Btu content, ambient
temperature, altitude, engine power and condition, etc.
COMMERCIAL SERIES
