Specifications
Performance:
Operating Frequency ISM Band 902-928MHz
Outdoor RF line-of-sight range External dipole antennas: 430 ft (131 m)
Outdoor to Indoor (through wall) range 100 ft to wall, 100 ft inside building (typical).
Range inside building will vary according to:
 Distance of outdoor transceiver from
outdoor/indoor interface (wall).
 Type of interface i.e. brick, aluminum
siding, stone, tinted windows using
metalized tint.
 Orientation of transceiver antennas (to
each other).
 Number and type of internal walls,
between transceivers, within building.
Transmit Power Output Internal antenna: -2.8 dBm
External dipole antenna -5.3 dBm
Throughput Data rate 2400 baud
Receiver Sensitivity -102 dBm
Power Requirements:
Supply Voltage (Regulated)
3 ± 0.15Vdc
Receive Current 13.6mA
Transmit Current 25.4mA
Standby Current
< 500nA
General:
Dimensions 1.25in x 1.05in x 0.16in
(32.0mm x 26.5mm x 4.2mm)
Weight without SMA connector 0.2oz (6g)
with SMA connector 0.3oz (9g)
Antenna Options
without SMA connector Insulated tinned-Cu wire 3.82in (97.0mm),
stripped 0.12in (3.0mm).
with SMA connector Nearson S467AH-915 (SMA rev polarity)
Operating Temperature
-40°C to +85°C
Agency Approvals:
FCC Part 15.249 VDE-0H7699
Industry Canada (IC) 8036A-0H7699
