Section 4 — Mounting Dimensions
Generac GTS “W” Type Transfer Switch
Mounting Dimensions – Drawing No. 0D3714-B
180
514
612
490
430
Values are in Millimeters
Note: Diameter of Mounting holes (A) is 6.35 MM
