ML-LSR LightSeeker Remote FOR POWERHOUSE, PORTABRIGHT, AND ENDEAVOR MONOLIGHTS USER MANUAL
THANK YOU FOR CHOOSING GENARAY INTRODUCTION 2 The Genaray ML-LSR LightSeeker Remote is a dedicated remote for Genaray’s Powerhouse, PortaBright, and Endeavor LED monolights as well as select Genaray lights that support the LightSeeker remote system. The 16-channel remote controls dimming on all models from 0% to 100% in 10% increments, and color temperature on bi-color models from 3200 to 6500 K in 100 K increments. The 2.
· Please read and follow these instructions, and keep this manual in a safe place. · Keep this unit away from water and any flammable gases or liquids. · Do not attempt to disassemble or repair this product. Doing so will void the warranty, and Genaray will not be responsible for any damage. Precautions PRECAUTIONS · Install the batteries in the proper orientation. Installing batteries in the reverse orientation can cause them to leak, overheat, or explode. · Remove the battery when storing the remote.
Power buttons LCD screen Color temperature buttons PRODUCT OVERVIEW On/off button Lock switch Channel select button Up button Down button Locking ring Mounting foot 4 LightSeeker Remote for Powerhouse, PortaBright, and Endeavor Monolights - USER MANUAL
1. Remove the battery cover and install two AA batteries. Make sure they’re in the proper orientation. Then replace the battery cover. 2. Press and hold the on/off button until the screen illuminates. Note: After 5 minutes of inactivity, the remote will switch to standby mode to preserve battery life. To wake up the remote, press any button to display the control screen. CHANNEL SELECTION Press the channel select button to highlight the current channel setting. Use the up/down buttons to set the channel.
ADJUSTING THE SETTINGS Instructions Color Temperature Brightness 1. Press the group’s color temperature button to highlight the current setting. 1. Press the group’s power button to highlight the current setting. To access group E, press and hold the group D power button until group E appears on the display. Press and hold the group E power button to return to group D. 2. Use the up/down buttons to change the color temperature from 3200 to 6500 K in 100 K increments.
Press and hold the power button until the LCD screen turns off. If the lights are still on, they will remain at the last values that were set on the remote. The color temperatures and brightness settings can still be adjusted via their onboard controls. SPECIFICATIONS Channels: 16 Groups: 5 Functions Supported: D imming, color temperature (bi-color LEDs) Frequency: 2.4 GHz Frequency Range: 100 ft. (30.5 m) Power: AA Battery (×2) Dimensions: 2.8 × 4.1 × 1.5 in. (7.1 × 10.5 × 3.8 cm) Weight: 4.75 oz.
ONE-YEAR LIMITED WARRANTY This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
