CR-10B CRUX USER MANUAL Crux Bi-Color LED - USER MANUAL 1
Thank you for choosing Genaray. The Crux CR-10B is a ten-inch bi-color LED array that Crux Bi-Color LED INTRODUCTION emits up to 2460 Lux (at 0.5 m) of flicker-free, continuous light. It draws only 28 W to deliver the equivalent output of a 250 W tungsten bulb. The Crux LED produces a 65° beam that’s ideal for interviews and tabletop photography, as well as other applications where it’s necessary to place the lights close to your subjects.
INTRODUCTION outstanding color accuracy. A built-in diffuser softens the light emitted by the 120-LED array, and it eliminates the multiple shadows that are often associated with LED lighting. The LED bulbs generate minimal heat, which allows you to place the fixture close to heatsensitive subjects, like models, animals, or food, without causing discomfort or damage.
CONTENTS INCLUDE CONTENTS 4 · Genaray Crux 10-Inch Round Bi-Color LED with Yoke · Battery charger with power cord · Sony NP-F battery type · Carry case Crux Bi-Color LED - USER MANUAL · AC adapter with power cord
· Please read and follow these instructions, and keep this manual in a safe place. · Handle the unit with care. · Keep this unit away from water and any flammable gases or liquids. · Clean the unit with only a soft, dry cloth. · Make sure the unit is powered off when plugging it into a power source. · Keep this unit away from children. · Use only the correct, recommended voltage.
Front diffuser (not removable) PRODUCT OVERVIEW Tilt locking knob Locking knob 6 Crux Bi-Color LED - USER MANUAL 5/8 in.
Battery release button Channel selector Battery indicator Color temperature control Power switch DC power input Battery contacts Crux Bi-Color LED - USER MANUAL 7 PRODUCT OVERVIEW Brightness control
MOUNTING THE LIGHT INSTRUCTIONS 1. Loosen the locking knob, and insert the 5/8-inch receiver over a light stand’s 5/8-inch stud. Tighten the locking knob until secure. 2. Adjust the angle of the light, and tighten the tilt locking knob. INSTALLING THE BATTERY (OPTIONAL) Make sure the power switch is in the OFF position. 1. Align the battery terminals on the battery with the contacts in the battery mount. 2.
1. Insert the battery into the battery charger. 2. Plug the charger’s power cord into a wall socket. The LED indicator will glow red when the battery is charging. When the LED indicator turns green, the battery is fully charged. Remove it from the charger, and insert it into the light’s battery mount. CONNECTING THE POWER CORD The CR-10B LED will operate on AC power, even if the battery is not installed. INSTRUCTIONS CHARGING THE BATTERY Make sure the power switch is in the OFF position. 1.
OPERATING THE LIGHT INSTRUCTIONS Powering On Syncing the Crux with Another Light To power on the light, slide the power switch in the direction of either the battery icon or the plug icon depending on the desired power source. The Crux CR-10B LED has an integrated transmitter/receiver that allows you to control select Crux LEDs from one fixture. Setting the Color Temperature Tap the color temperature control icons to change the color temperature in 50 K increments. 2.
LED count: 120 AC operating voltage: 100 to 240 V, 50/60 Hz Color temperature: 3000 to 5600 K DC operating voltage: 15 V DC, 3 A Dimming: 100% to 0% Bulb life: 30,000 hr. Luminance: 5600 K: 2460 lx @ 0.5 m Battery: Sony NP-F battery type 3000 K: 2310 lx @ 0.5 m AC cable length: 9.3 ft. (2.8 m) Coverage: 65° DC cable length: 3.75 ft. (1.1 m) CRI: 95 Weight: 2.5 lb. (1.1 kg) Electrical consumption: 28 W Dimensions (W × H × D): 14.6 × 13.6 × 2.4 in.
ONE-YEAR LIMITED WARRANTY This GENARAY product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
