User Manual
Table Of Contents
- Nokia A036 Wireless LAN Access Point User Manual
- Contents
- 1 Introduction to Nokia A036 Wireless LAN Access Point
- 2 Install
- 3 Upgrade
- 4 Commission
- 5 Administer
- 5.1 Accessing command line interface
- 5.2 Accessing web user interface
- 5.3 Changing password
- 5.4 Setting internet access
- 5.5 Setting access to management functions
- 5.6 Enabling Zone Privacy
- 5.7 Configuring DHCP
- 5.8 Uploading configuration file via TFTP
- 5.9 Uploading and downloading files via FTP
- 5.10 Using SNMP
- 6 Statistics
- 7 Commands, parameters and alarms
- 8 Files
Reception sensitivity min. -90 dBm
EMC emissions FCC class B requires the use of shielded Ethernet cable.
FCC/EN55022 class A.
EMC immunity EN55024
Storage temperature 0 - 60 degrees celcius
Operating temperature 0 - 40 degrees celcius
Radio
WLAN standard IEEE802.11b
Default settings Wi-Fi Interoperability Test Plan version 1.1a
Channels 13 (depending on local regulations)
Max data rate 11 Mb/s
Modulation technique Direct Sequence Spread Sprectrum (DSSS)
Functional specifications
Management options Web based, Telnet, SNMP
Management connection Ethernet, air interface
File transfer FTP, TFTP
Access security WEP (40 bits, 128 bits)
Multi-Access Point roaming Nokia Inter Access Point Protocol
LED indicator Power status
Interfaces
Ethernet connection IEEE802.3 automatic 10/100baseT (RJ-45)
Power over Ethernet IEEE802.3 af
Power supply EU, UK and US standard AC power
dn02119532
Issue 1-0 en
# Nokia Corporation
Nokia Proprietary and Confidential
9 (60)
Introduction to Nokia A036 Wireless LAN Access Point
