User Manual

Antennas
Nokia A036 is equipped with fully balanced and high quality internal antennas
resulting in an optimal RF performance. The antennas have been designed to
optimise coverage and reception propability when Nokia A036 is wall mounted.
Nokia A036 also allows the installation of external antennas. External antennas
may be needed if the access point needs to be hidden or, for example, an omni-
directional coverage is required. Three different types of external antennas are
available by order. For more information on external antennas, see Nokia A036
technical specification.
Wi-Fi 802.11b functionality
Nokia A036 Wireless LAN Access Point follows the Wi-Fi recommendation for
default settings, as specified in the Wi-Fi System Interoperability Test Plan
version 1.1a. Therefore, Nokia A036 needs no reconfiguration to achieve Wi-Fi
compatibility.
1.2 Nokia A036 technical specifications
Physical specifications
Product name Nokia A036 Wireless LAN Access Point
Type Stand alone unit
Dimensions 202mm x 152mm x 29mm (8" x 6" x 1")
Weight 350g
Standards IEEE802.11b (Wireless LAN), IEEE802.3 (Ethernet), IEEE802.3af
(PoE)
Internal antenna Sector
External antenna OMNI, dual slant sector, bi-sector, with 2m/6ft cable
Electrical specifications
Power source Power over Ethernet, 110V - 230V AC 50/60Hz (EU, UK, US)
Operating power consumption < 5 W
Output power max. 20 dBm
8 (60) # Nokia Corporation
Nokia Proprietary and Confidential
dn02119532
Issue 1-0 en
Nokia A036 Wireless LAN Access Point User Manual
