8 Files
8.1 config.txt
The configuration file is a text file containing all configurable parameters of
Nokia A036. You can modify the parameters in the configuration file and then
upload the file to Nokia A036 using FTP or TFTP. After a successful upload,
Nokia A036 will first check the validity of parameters and then change the
settings according to the configuration file.
Record structure of the file
%channel: 10
%domain: us a
%net_name: "Nokia WLAN"
%frag_threshold: 234 6
%rts_threshold: 2301
%short_retry: 8
%long_retry: 4
%Basic_rate: All
%beacon_interval: 10 0
%dtim_interval: 1
%ed_threshold: 127
%wep_mode: "open"
%ip_address: none
%subnet_mask: 255.25 5.0.0.
%ip_address_OpenSystem: none
%ip_address_1x: none
%gateway: none
%telnet_port: 23
%http_port: 80
%manager: "any"
%ap_name: "LocalAP"
%protocol_filter: al l
%zone_privacy: off
%community_get: "public"
%community_set: "private"
%snmp_contact: "Cont act"
%snmp_sys_name: "Sys Name"
%snmp_location: "Location"
%snmp_secret: "defau lt"
%snmp_enable_set: "o ff"
