User Manual

Parameter Default value Range Description
ters in sets of a - z,
A - Z and 0 - 9
shared secret for the radius
server.
snmp_enable_set off on, off Enable or disable SNMP SETs
snmp_enable_get off on, off Enable or disable SNMP GETs
snmp_enable_trap off on, off Enable or disable SNMP traps.
cca_mode {param} cs_only ed_only, cs_only,
ed_and_cs,
ed_or_cs
Specifies the CCA (Clear
Channel Assessment) to be
used.
wep_key {1-4} {KEY} none 1-4, hex string Sets default key to value hex
string. The hex string will be 10
or 26 hex characters, according
to the strength of WEP key
being entered (note: the web
user interface allows these
keys to be entered also in
ASCII.)
wep_key_length {[normal |
high]}
normal normal, high "normal" sets the wep-key
length to 40 bits, "high" sets the
wep-key length to 128 bits
wep_key_active {1-4} 1 1-4 Specifies which one of the four
wep keys is active.
radius_server {1-2} {ip_addr} none 1 or 2, IP ad-
dresses
IP address of primary (1) and
secondary (2) Radius servers.
shared_secret {1-2} {secret} none up to 16 charac-
ters
An ASCII string giving the
shared secret for the Radius
server.
shared_password {password} Nokia WLAN up to 16 charac-
ters
An ASCII string giving the
dummy password for the Ra-
dius server.
ip_address_ac {dotted-quad} none IP address Access Controller IP address in
a configurable parameter in
Access Point.
dhcp_relay {[on | off]} off on or off Enables the DHCP relay func-
tionality.
brgtable {[add | del] {MAC}} none add or del Adds/deletes a given MAC ad-
dress to/from bridge table.
manager_ip {1-4} {ip_addr} none 1-4, IP address Allows one of out of four IP
addresses specific manage-
dn02119532
Issue 1-0 en
# Nokia Corporation
Nokia Proprietary and Confidential
53 (60)
Commands, parameters and alarms
