User Manual

Parameter Default value Range Description
japan
net_name {name} Nokia WLAN up to 32 charac-
ters
802.11 network name (ASCII,
case-sensitive)
frag_threshold {value} 2346 256-2346 (even
numbers only)
Fragmentation threshold for
802.11 packets. Frames larger
than this value will be broken
into multiple smaller packets.
rts_threshold {value} 2301 0-2347 The size of data frame above
which the IEEE802.11 RTS/
CTS collision avoidance meth-
od is used.
short_retry {value} 8 0-31 The number of times a frag-
ment is retried in the event of a
transmission failure.
long_retry {value} 4 0-31 The number of times a frame is
retried in the event of a trans-
mission failure.
basic_rate {rates} All 1000 2000, 5500
11000, All
A list of all basic rates sup-
ported by the access point (this
should be limited to rates that
all stations can support).
beacon_interval {value} 100 1-65535 The time interval between
beacons (in milliseconds).
dtim_interval {value} 1 1-255 The number of beacons to
count between DTIMs.
ed_threshold {value} 127 10-127 Energy detection threshold.
wep_mode {mode} open Determines the Access Point
authentication policy:
open Accept open system.
wep Wep key is required.
ip_address {dotted-quad} none IP address IP address of the Access Point
(for management purposes).
ip_address_OpenSystem
{dotted-quad}
none IP address IP address of the AP to be used
in DHCP relay when forwarding
requests for OpenSystem
users.
dn02119532
Issue 1-0 en
# Nokia Corporation
Nokia Proprietary and Confidential
51 (60)
Commands, parameters and alarms
