aRetry_Count Number of frames resent.
aMultiple_Retry_Count Occurrences when multiple retries were needed to
send a frame.
aFrame_Duplicate_Count Count of RTS that received no response.
aRTS_Success_Count Count of CTS received in response to RTS.
aRTS_Failure_Count Count of RTS that received no response.
aACK_Success_Count Number of times ACK was not received after
transmission.
aReceived_Frame_Count Number of received frames.
aMulticast_Received_Count Number of Multicast frames received.
aFCS_Error_Count Number of frames received with checksum errors.
6.2 Measuring LAN interface
The Nokia A036 web user interface provides information on the following LAN
statistics:
Bytes received Total number of bytes received.
Unicast packets received Number of unicast packets received.
Nonunicast packets received Number of nonunicast packets received.
Received packets dropped Number of received packets dropped.
Received packets errors Number of received packets dropped by errors.
Bytes transmitted Total number of bytes transmitted.
Unicast packets transmitted Total number of bytes transmitted.
Nonunicast packets transmitted Number of nonunicast packets transmitted.
Transmitted packets dropped Number of transmitted packets dropped.
Transmitted packets errors Number of transmitted packets dropped by errors
