User Manual

SSID (Service Set ID) 802.11 network name.
Radio channel The channel that the Access Point uses to transmit and receive
information.
Regulatory domain The domain for which the device is certified. The amount of
available radio channels depends on the regulatoy domain.
Basic rate You can choose all or specific. If specific, select either low or high
rate.
Peer AP's for wireless distribution system. You can list MAC addresses of peer Access Points after which the
Access Point will try to establish a link with those listed. In this
way the AP's will form a wireless backbone or a wireless
distribution system.
Configuring wireless settings via command line interface
To configure wireless settings via command line interface, set the following
parameters using the set command:
Parameter Default value Range Description
net_name {name} Nokia WLAN up to 32 charac-
ters
802.11 network name (ASCII,
case-sensitive)
channel {value} Radio channel and domain are
linked: the domain parameter
selects the regulatory domain
governing channel assignment,
and is used to constrain the
choice of channels.
10 1-13 ETSI
10 1-11 USA and Canada
10 10-13 France
14 14 Japan
domain {[usa | canada | etsi |
france | japan]}
usa usa
canada
etsi
france
japan
The regulatory domain.
32 (60) # Nokia Corporation
Nokia Proprietary and Confidential
dn02119532
Issue 1-0 en
Nokia A036 Wireless LAN Access Point User Manual
