3 Upgrade
3.1 Upgrading via TFTP
Use TFTP client software and command line interface to upgrade Nokia A036.
The uploaded file can be a plain image file (system, rescue or MVC), or if the file
is tarred and compressed, more images can be uploaded in a single upload session
Steps
1. Run your TFTP software and input the following information:
<HOST>: IP address of Nokia A036
<Port>: 69 (port number for TFTP)
<LocalFirmwareFile>: the name of the new firmware file
you want to upgrade
<RemoteFileName>: pa ssword of the Web/SNMP
(default password: private)
2. On the workstation, click Start -> Run to open a command window
3. In the command window, type the following command:
tftp-i <IP A ddress> put <FirmwareFile> <RemoteFileName>
where
<IPAddress> = IP address of Nokia A036
<FirmwareFile> = name of the firmware
<RemoteFileName> = password of Web/SNMP
(default password: private)
Note
Make sure that the file is available in the directory from where you run this
command.
