1 Introduction
This document describes the hardware interface of the Siemens MC55/56 module that
connects to the cellular device application and the air interface. As MC55/56 is intended to
integrate with a wide range of application platforms, all functional components are described
in great detail.
This guide therefore covers all information needed to design and set up cellular applications
incorporating the MC55/56 module. It aids rapid retrieval of interface specifications, electrical
and mechanical details and information on the requirements to be considered for integration
of further components.
1.1 Related documents
[1] MC55 AT Command, Version 03.00
MC56 AT Command, Version 03.00
[2] MC55/56 Release Notes, Version 03.00
[3] GPRS Startup User's Guide
[4] Remote-SAT User's Guide
[5] DSB45 Support Box - Evaluation Kit for Siemens Cellular Engines
[6] Application Note 23: Installing MC55/56 on DSB45
[7] Application Note 07: Li-Ion Batteries in GSM Applications
[8] Application Note 16: Upgrading MC5x Firmware, Version 06
[9] Application Note 14: Audio and Battery Parameter Download
[10] Application Note 02: Audio Interface Design
[11] Multiplexer User's Guide
[12] Multiplex Driver Developer’s Guide for Windows 2000 and Windows XP
[13] Multiplex Driver Installation Guide for Windows 2000 and Windows XP
[14] Application Note 22: Using TTY / CTM equipment
[15] Application Note 24: Application Developer’s Guide
[16] Application Note 28: Customer SIM Lock
Prior to using the MC55/56 engines or upgrading to a new firmware release, be sure to
carefully read the latest product information.
To visit the Siemens Website you can use the following link:
http://www.siemens.com/wm
