1 Introduction
10
1 Introduction
This document
1
describes the hardware of the Cinterion
®
EHS6-A module. It helps you quickly
retrieve interface specifications, electrical and mechanical details and information on the
requirements to be considered for integrating further components.
1.1 Key Features at a Glance
Feature Implementation
General
Frequency bands GSM/GPRS/EDGE: Quad band 850/900/1800/1900MHz
UMTS/HSPA+: Five band 800/850/900/1900/2100MHz
GSM class Small MS
Output power
+33dBm ±1dB for EGSM850
+30dBm ±1dB for GSM1900
+27dBm ±1dB for EGPRS 850(8-PSK, 1 Tx slot)
+24dBm ±1dB for EGPRS 850(8-PSK, 2 Tx slot)
+22dBm ±1dB for EGPRS 850(8-PSK, 3 Tx slot)
+21dBm ±1dB for EGPRS 850(8-PSK, 4 Tx slot)
+26dBm ±1dB for GPRS 1900(8-PSK, 1 Tx slot)
+23dBm ±1dB for EGPRS 1900(8-PSK, 2 Tx slot)
+21dBm ±1dB for EGPRS 1900(8-PSK, 3 Tx slot)
+20dBm ±1dB for EGPRS 1900(8-PSK, 4 Tx slot)
+33dBm ±1dB forGPRS 850(GMSK, 1 Tx slot)
+30dBm ±1dB for GPRS 850(GMSK,2 Tx slot)
+28dBm ±1dB for GPRS 850(GMSK, 3 Tx slot)
+27dBm ±1dB for
GPRS 850(GMSK, 4 Tx slot)
+30dBm ±1dB for GPRS 1900(GMSK, 1 Tx slot)
+27dBm ±1dB for GPRS 1900(GMSK, 2 Tx slot)
+25dBm ±1dB for GPRS19050(GMSK, 3 Tx slot)
+24dBm ±1dB for GPRS 1900(GMSK, 4Tx slot)
+24dBm ±1dB for UMTS Band 2
+24dBm ±1dB for UMTS Band 5
Power supply 3.3V to 4.5V
Operating temperature
(board temperature)
Normal operation: -30°C to +85°C
Extended operation: -40°C to +90°C
Physical Dimensions: 27.6mm x 25.4mm x 2.2mm
Weight: approx. 3.5g
1
. The document is effective only if listed in the appropriate Release Notes as part of th e technical
documentation delivered with your Gemalto M2M product.
