User manual

OPERATING THE
4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS
Setting the IR Channel
Inorderforthe4x4 Matrix for HDMI w/4 ELR-POLtocommunicatewiththeincludedIRRemote
Control,boththematrixandtheIRRemoteControlmustbesettothesameIRchannel.Follow
theprocedureoutlinedbelowtosettheIRchannelonthe4x4 Matrix for HDMI w/4 ELR-POL.
1. FromtheRoutingscreen,simultaneouslypresstheInput - ,Input +,andthe
Output -buttonstodisplaytheIRaddressscreen.ThecurrentIRaddresswillbe
displayedalongwiththeDIPswitchsettingsfortheIRremotecontrol:


















2. UsetheInput +(orInput -)buttontochangetheIRchannel.PresstheInput -button
todecreasetheIRchannelvalue.PresstheInput +buttontoincreasetheIRchannel
value.
21
4
3
IR ADDRESS : 1
1-ON , 2-OFF
DIPswitchsettings
IRChannel
