Range Hood User Manual Model: GWS-M30A Customer Service: 1-844-801-8880 IMPORTANT: DO NOT use this range hood until you have read this entire manual. Please keep it for future reference.
1. Warning & Caution………………………………………Page 3-4 2. Prepare the hood………………………………………..Page 5-7 3. Install the hood…………………………………………..Page 8 4. Maintenance……………………………………………..Page 9 5. How to use…………………………………………….....Page 10 6. Parts list……………….………………….……………….Page 11 7. Troubleshooting…………...……………………………...
WARNING To reduce the risk of fire, electric shock, or injury to persons, observe the following: 1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the address or telephone number listed in the warranty. 2. Before servicing or cleaning unit, switch power off at service panel and lock service panel to prevent power from being switched on accidentally.
WARNING To reduce the risk of injury to persons in the event of a range top grease fire, observe the following: 1. Smother flames with a close-fitting lid, cookie sheet, or metal tray, then turn off the burner. Be careful to prevent burns. If the flames do not go out immediately, evacuate and call the fire department. 2. Never pick up a flaming pan - You may be burned. 3. Don’t use water, including wet dishcloths or towels - violent steam explosion will result. 4.
PREPARE THE HOOD Unpack hood and check contents.
1RWH This range hood must be properly grounded. The unit should be installed by a qualified electrician in accordance with all applicable national and local electrical codes. The minimum hood distance above cook top must not be less than 24’’. A maximum of 33” above cook top is highly recommended for best capture of cooking impurities. Distances over 33” are at the installer and users discretion. INSTALL THE DUCTWORK Note: To reduce the risk of fire, use only metal ductwork. 1.
INSTALL MOUNTING BRACKETS 1. After evaluating the height of the hood, place the hook center over installation location. Drill 3 holes of Ø8mm on a suitable place to fix the mounting brackets. 2. Put the drywall anchors into the holes and fix the mounting screws (4x40mm) into the anchors, and install the hook on the wall as shown. INSTALL SLIDERY DUCT, FIXING SUPPORT 1.
INSTALL THE HOOD Note: at least two people will be required to mount the hood. 1. Raise the hood into its mounting position. 2. Align the rectangular opening on the back of the hood with the wall-mounting bracket. Gently lower the hood until it securely engages the bracket. 3. Open the Al. filter and find the two φ8 mm holes on the back of the hood. Level the hood with 2 mounting screws (4*30mm) with washer. Use drywall anchors provided. 4.
MAINTENANCE Proper maintenance of the Range Hood will assure proper performance of the unit. Filters The filters must be cleaned approximately once every 30 hours of operation (when the central segment on the display goes on or starts blinking). Use a warm detergent solution. Grease filters are dishwasher safe. Remove filter by pushing filter towards the back of hood and rotating filter downward. Duct free (Carbon) Filters-buy separately Filter The duct free filters should be changed every 6 months.
TOUCH CONTROLS After you have connected the appliance to the mains supply the backlight will turn on. It will turn off after 5s without any operation and the hood will enter stand-by mode. Press one of the speed buttons Press the button for low speed. Push the button again and the motor will stop. Press the button for medium speed. Push the button again and the motor will stop. Press the button for high speed. Push the button again and the motor will stop. Press the button off.
PARTS LIST No.
TROUBLESHOOTING Problem Light on, but motor does not work Cause Solution The leaf blocked Get rid of the blocking The capacitor damaged Replace capacitor The motor jammed bearing damaged Replace motor The internal with of motor off or a bad smell from the motor Replace motor Beside the above mentioned, check the following: Light does not work, motor does not work Oil leakage Shake of the body Insufficient suction Light damaged Replace lights Power cord looses Connect the wires as per the
Customer Service: 1-844-801-8880 E-mail: info@home-easy.net www. geekappliances.
