Specification

GDT535PSM
GE
®
Dishwasher with Hidden Controls
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
For answers to your Monogram, GE Café
™
Series, GE Profile
™
Series or
GE Appliances product questions, visit our website at geappliances.com
or call GE Answer Center
®
Service, 800.626.2000.
Specification Revised 9/18
Listed by
Underwriters
Laboratories
As an ENERGY STAR
®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
This Wall Area
must be Free
of Pipes or
wires
33-1/2" to 34-3/4"
Underside of
Countertop
to Floor
Figure A
Cabinets
Square
and
Plumb
24"
Min.
4"
6"
Plumbing and Electric Service
Must Enter Inside This Area
24"
Min.
ELECTRICAL RATING
Voltage AC................................................................120
Hertz..........................................................................60
Total connected load amperage................................7.1
Calrod
®
heater watts max................................800/500
For use on adequately wired 120-volt, 15-amp circuit
having 2-wire service with a separate ground wire.
This appliance must be grounded for safe operation.
INSTALLATION INFORMATION: Before installing,
consult installation instructions packed with product
for current dimensional data.
27-1/2"
24"*
MAX.
23-3/4"
3/ "
to
33- 8 MIN.
.
adj
34-5/8"
AX
M
4"(toekick)
29-7/8"
*Add 2.4" for handle.
