2.6 CONVERTER SIZE SELECTION
Within the specified voltage field, the CS300 converter supplies the same rated direct current independently of
the voltage itself. The increase of the output voltage causes an increasing in the transferred power, whereas
inverters are devices with a typically constant transferred power (the supplied current decreases with the increasing
of the output voltage).
As for the choice, therefore, the calculation is based on a common unit, the direct current of the intermediate
circuit, which, as for the inverters, is not mentioned into the product instruction manual and has therefore to be
calculated. Furthermore, the confrontation between the two foreseen functioning classes has to be homogeneous
(IEC 146 class 1 and 2).
2.6.1 Output Rated Currents for the Two Functioning Classes
DC link current (Terminals C / D)
IEC 146 Class 1 * IEC 146 Class 2 **
6KCS3185-480
185 A 150 A
6KCS3280-480
280 A 225 A
6KCS3420-480
420 A 340 A
6KCS3650-480
650 A 540 A
6KCS310H-480
1050 A 850 A
6KCS315H-480
1500 A 1300 A
cs060
* Continuous service
Converter
** Service with overload possibility of 150% for 60 seconds
