Chapter 2 - COMPONENT IDENTIFICATION AND SPECIFICATION
2.1 GENERAL DESCRIPTION
CS300 is a half-controlled three phase AC/DC converter for supplying DC link voltage to a series of AC Drives,
with C and D terminals parallel connected.
The precharge of the drive capacitors (time setting set via dip-switches) is done by partializing the mains
voltage via a thyristors bridge. A diagnostic circuit allows detection of a mains power supply dip for
system use.
NOTE! The direct parallel connection of the outputs (U2,V2,W2 terminals) of two or more inverters
is not possible !
2.2 POWER SUPPLY
CS300 converter can be connected to the three phase power supply having the following characteristics:
400V-15% up to 480+10%
50 or 60 Hz (Dip-switch selectable)
The maximum input power of the internal switching power supply is 100W, and the supplied voltages are:
+/-15V 500mA Control card
+24 V 2A Fan power supply (if present) and auxiliary functions (regulator
terminals power supply)
2.3 DESCRIPTION OF POWER TERMINALS
Terminals Function
U, V, W Power supply via AC mains, 3Ph (400V –15% up to 480V +10%)
C Positive terminal to be connected to the inverter DC-LINK
D Negative terminal to be connected to the inverter DC-LINK
Supply for internal fan (only for 1050A size and higher)
(1Ph, 230V ± 15%)
cs010
U3, V3
