WALL CASE DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)

Total volume and shelf

area are calculated by

the Association of Home

Appliance Manufacturers’

standards.

Listed by

Underwriters

Laboratories

For answers to your Monogram, GE Café

™

, GE Profile

™

or GE Appliances

product questions, visit our website at geappliances.com or call

GE Answer Center

Service, 800.626.2000.

Specification Created 7/20

AJEM12DCH

Premium, Deluxe and Value Model

Wall Case Dimensions (in inches)

Note: When installing units in through-the-wall applications.

Do not restrict air flow areas.

15-5/8

21-13/16

16-7/8

AJEM12DCH

230/208 Volt Built-In Heat/Cool Room Air Conditioner

Note: When installing slide-out chassis units in through-the-

wall applications, keep louvers free. Do not restrict air flow

areas..

Perpendicular

230/208V

20 Amp

PAGE 1
AJEM12DCH GE® 230/208 Volt Built-In Heat/Cool Room Air Conditioner WALL CASE DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES) Note: When installing slide-out chassis units in through-thewall applications, keep louvers free. Do not restrict air flow areas.. Premium, Deluxe and Value Model Wall Case Dimensions (in inches) 15-5/8 Perpendicular 16-7/8 230/208V 20 Amp 26 21-13/16 Note: When installing units in through-the-wall applications. Do not restrict air flow areas.
PAGE 2
AJEM12DCH GE® 230/208 Volt Built-In Heat/Cool Room Air Conditioner WALL CASE DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES) INSTALLATION INFORMATION: A finished opening of 26-1/8" x 15-3/4" clear of intrusions is required. Keep clearance of 4" from side walls. Brick veneer or frame walls should have wood studding surrounding case to provide firm anchoring with screws. Case can be fastened directly to brick or block walls with screws sunk in lead expansion shields.
PAGE 3
AJEM12DCH GE® 230/208 Volt Built-In Heat/Cool Room Air Conditioner FEATURES AND BENEFITS True Built In Design – The ultimate fit & finish for more usable space and the best in built-in installation.
