Data Sheet

Lens selection by application
The Albeo™ ABHG-series optical lens system enables LEDs to provide precise illumination where needed. Lenses are
designed for commercial & industrial applications where mounting height, fixture spacing & light levels help determine lens
selection. The following table outlines lens options and suggested application. Consult factory for specific project layouts.
LENS TYPE MOUNTING HEIGHT SPACE TYPE
Diffused 120° Below 20 Feet Open Floor Plan
Standard 120° Any Open Floor Plan
80° Any Open Floor Plan
40° Below 20 feet Low Bay Racked Aisles
30° Above 20 feet High Bay Racked Aisles
20° Above 20 feet High Bay Racked Aisles
Diffused 30° Below 20 feet Low Bay Racked Aisles
