User Manual Part 7

Technical specifications
2001989-301A- draft 1 ApexPro™ E-3
Environmental specifications
Operating conditions
Storage conditions
Device specifications
A/D converter resolution 10 bits, 9.75 µV (RTI)
Sample rate 240 samples/seconds
Temperature 5 to 40° C
Relative humidity 15 to 95% (non-condensing)
Temperature -20 to 70° C
Relative humidity 15 to 95% (non-condensing)
Pressure 700 to 1060 hPa
Water resistance IEC 60529 IPX7 rating (can survive inadvertent submersion)
Input configuration 3, 5 or 6 electrodes
Frequency range
Modulation GFSK
Serial I/O ports 2
Alarm pause Transmitted and indicated via LED
Graph request Transmitted
Event Marker Transmitted
Attendant request Transmitted
Maximum transmitters 239 active within WTMS at a single facility
Dynamic range ± 5 mV (RTI)
Input offset ± 400 mV (RTI)
Input impedance 15 M ohm minimum differential @ 10 Hz
ECG gain selection 5, 10, 20, 40 mm/mV (RTI)
ECG gain accuracy ± 5% @ 15 Hz
Common mode rejection 100 dB minimum @ 60 Hz
Defibrillator protection ± 5000 VDC, 360 joules into 100 ohm
Defibrillator recovery time Transmitter recovers within 2 seconds
Draft
