E-2 ApexPro™ 2001989-301A- draft 1
Technical specifications
NOTE
Specifications are provided to help you determine the space, ventilation, air
conditioning and power requirements to ensure proper operation of your system.
Specifications are approximate and may change with the actual unit shipped.
Specifications are subject to change without notice. Contact your sales or service
representative for more information.
T14 transmitters
Power requirements
Alarms and controls
Transmission
ECG
Battery type ANSI/NEDA 15 A, 1.5V AA alkaline (2 required)
Battery life hours
Polarity Electronic reverse polarity protection
Battery integrity Transmitted and indicated via LED
Leads Fail indication Transmitted and indicated via LED
Channel spacing 25 kHz
Frequency stability ± 0.0001% of assigned channel frequency
Bit rate 10 kbps
Antenna Formed by leadwire shield
Multi-channel configuration
(5- or 6- leadwire)
I, II, III, Va, Vb, aVR, aVL, aVF
Leads analyzed
simultaneously
Four (I, II, III, V)
Single-channel (3-leadwire)
configuration
I, II or III, configurable
Heart rate detection 30 to 300 BPM
QRS detection range 0.5 to 5 mV
Frequency response 0.05 to 40 Hz (-3 dB)
