Printing
2001989-301A- draft 1 ApexPro™ 9-7
081A
3. Change any of the undimmed setting options. When an option appears dimmed,
you cannot change it unless you enter the service-level password.
Enable transmitter graph
The Enable Transmitter Graph option allows you to turn off/on the Transmitter
Graph function for telemetry patients. When this option is enabled at the CIC Pro
center, you can initiate a graph by pressing the graph button on the transmitter. When
this option is disabled at the CIC Pro center, no graph can be initiated from the
transmitter. To enable or disable this option, follow this procedure:
1. To enable the Transmitter Graph option, point and click with the mouse to place
a check mark in the Enable Transmitter Graph check box.
Option Function
Graph Waveforms Set the print order of the ECG waveforms:
 ECG 1: Set the lead and its associated waveform to
print first.
 Waveform 2: Set the ECG lead or parameter and its
associated waveform to print second.
 Waveform 3: Set the ECG lead or parameter and its
associated waveform to print third.
 Waveform 4: Set the ECG lead or parameter and its
associated waveform to print fourth.
Graph Location Choose from available printers to set the graph location
of the manual, alarm, and print window graphs:
 Manual: Any real-time patient data you initiate the
printing of.
 Alarm: An alarm graph that is triggered by a patient
Crisis or Warning alarm condition.
 Print Window: Any stored patient data you initiate
the printing of. This graph location also prints the
Graph All > Limits data.
Enable Transmitter Graph Turn on or turn off the ability to initiate graph printing from
a transmitter.
Speed Set the print speed. The slower the speed, the more
condensed the data. 25 mm/second is standard.
