Architect and Engineering Manual
56
KIT NUMBER DESCRIPTION FOR ADDITIONAL INFORMATION REFER TO PAGE
RAA13 Replacement filter for the RAK13 kit 9
RAA64 Spare Filters for AZ45 and AZ65 (one pair per box) 12
RAB71B Steel Wall Sleeve – 13-3/4" deep 23
RAB7116B Steel Wall Sleeve – 16" deep 23
RAB7118B Wall Sleeve - 18” deep 23
RAB7120B Wall Sleeve - 20” deep 23
RAB7124B Steel Wall Sleeve – 24" deep 23
RAB78B Molded four piece Quick Snap design SMC wall sleeve 23
RAB81 Wall Sleeve - 13 3/4” deep Quick Snap design - ships in a flat package - field assembled 7-23
RAB81B Wall Sleeve - 13 3/4” deep Quick Snap design - fully assembled 7-23
RAB8116B Quick Snap Wall Sleeve 16” extended depth 23
RAB8118B Quick Snap Wall Sleeve 18” extended depth 23
RAB8120B Quick Snap Wall Sleeve 20” extended depth 23
RAB8124B Quick Snap Wall Sleeve 24” extended depth 23
RAD10 Interior/Exterior Drain kit 37–38
RAG60 Stamped Aluminum Exterior Grille 42
RAG61 Architectural Exterior Grille, Beige Molded High-Impact Plastic 42
RAG62 Architectural Exterior Grille, Maple Molded High-Impact Plastic 42
RAG63 Architectural Exterior Grille, Dark Brown Chocolate Molded High-Impact Plastic 42
RAG67 Aluminum Architectural Grille (Custom Colors Available by Special Order) 42
RAK13 MERV 13 Makeup Air kit with filter 9
RAK40 Condenser Air Deflector Kit 42
RAK44 PTAC Curtain Guard 13
RAK149P2 Wall Thermostat for Resistance Heat and Heat Pump Models – Electronic Digital Programmable 17-18
RAK149F2 Wall Thermostat for Resistance Heat and Heat Pump Models - Digital with Two Speed Fan 17-18
RAK180W1 Energy Management Occupancy Sensing Wired/Wireless Thermostat Makeup Air Compatible 17-19
RAK204D15C Sub-Base - 230/208-volt with NEMA 6-20R 15/20 Amp Receptacle – Power Cord and Chaseway included 25
RAK204D20C Sub-Base - 230/208-volt with NEMA 6-20R 15/20 Amp Receptacle – Power Cord and Chaseway included 25
RAK204D30C Sub-Base - 230/208-volt with NEMA 6-30R 30 Amp Receptacle –Power Cord and Chaseway included 25
RAK204E15C Sub-Base – 265-volt with NEMA 7-15R 15 Amp Receptacle – Power Cord and Chaseway included 25
RAK204E20C Sub-Base – 265-volt with NEMA 7-20R 20 Amp Receptacle – Power Cord and Chaseway included 25
RAK204E30C Sub-Base – 265-volt with NEMA 7-30R 30 Amp Receptacle – Power Cord and Chaseway included 25
RAK204U Sub-Base – non-electrical – Chaseway included 25
RAK205CW Chaseway for Sub-Base 25
RAK315P Universal Power Cord – AZ45/AZ65 – 15-Amp 230/208 V – 2.40/1.96 kW heat 43
RAK320P Universal Power Cord – AZ45/AZ65 – 20-Amp 230/208V – 3.4/2.78 kW heat 43
RAK330P Universal Power Cord – AZ45/AZ65 – 30-Amp 230/208V – 4.8/3.93 kW heat 43
RAK315SP 230/208V Universal power supply non-LCDI, short, 15 amp for 45 & 65 only - for use in sub-base only 25
RAK320SP 230/208V Universal power supply non-LCDI, short, 20 amp for 45 & 65 only - for use in sub-base only 25
RAK330SP 230/208V Universal power supply non-LCDI, short, 30 amp for 45 & 65 only - for use in sub-base only 25
RAK4002D Direct-Connect Junction Box – 230/208-volt units AZ45/AZ65 44
RAK315D 230//208V Direct Connection Kit, 15 AMP for AZ45/AZ65 - 2.4/1.96 kW heat 44
RAK320D 230//208V Direct Connection Kit, 20 AMP for AZ45/AZ65 - 3.4/2.78 kW heat 44
RAK330D 230//208V Direct Connection Kit, 30 AMP for AZ45/AZ65 - 4.8/3.93 kW heat 44
RAK515D Direct Connect Kit – 265V – 15 Amp – Use w/RAK204E15C Sub-Base – 2.40 kW heat 44
RAK520D Direct Connect Kit – 265V – 20 Amp – Use w/RAK204E20C Sub-Base – 3.40 kW heat 44
RAK530D Direct Connect Kit – 265V – 30 Amp – Use w/RAK204E30C Sub-Base – 4.80 kW heat 44
RAK515P 265V Short Power Connection Kit – Non LCD1, 15 AMP 2.40 kW heat - for use in sub-base only 44
RAK520P 265V Short Power Connection Kit – Non LCD1, 20 AMP 3.40 kW heat - for use in sub-base only 44
RAK530P 265V Short Power Connection Kit – Non LCD1, 30 AMP 4.8 kW heat - for use in sub-base only 44
RAK601B Duct Extension – Insulated – 44" long – includes Register and Trim Flange 39
RAK602B Register and Trim Flange (Included with RAK601B) 39
RAK6053 Duct Adapter for New Installation with AZ45/AZ65 Series 39
RAK7013 Duct Adapter for replacement of existing duct system with 8-3/8" x 6-1/2" Duct 42
RAK7023 Duct Transition for replacement of existing duct system with 7-3/32" x 6-1/2" Duct 42
RAKCDC CDC Wiring Connector for 45 & 65 16, 19
RAKVENT1 Manifold Kit added for fresh air intake through the vent door (non-Makeup Air models) 13
ACCESSORY LIST
ARCHITECTS & ENGINEERS DATA MANUAL AZ45/AZ65 SERIES
