REPLACEMENT INSTALLATIONS
GE offers duct adapters to allow for easy replacements
of previous-design chassis in ducted installations where
a GE duct adapter was used in the original installation.
A duct adapter is available that will align with the duct
extension when GE-built components were used in the
original installation.
The duct adapter/extension used from the early 1960s
until late 1987 was 8-3/8" high by 6-1/2" wide. If the
chassis to be replaced uses this size duct, use the duct
adapter model RAK7013 with the new product to match
up to the existing duct extension. This means the duct
extension will not have to be changed.
However, to keep the cost of the replacement to a
minimum there are components that will need to be
taken off the existing installation and reused on the
RAK7013 duct adapter. Therefore, save all parts from
the existing setup until after the installation is complete.
It is important that those parts not be discarded until
the new installation is complete.
If the existing duct dimensions are 7-3/32" high by 6-1/2"
wide, the RAK7023 transition piece is required to install
an AZ45 or AZ65 Series unit in the ducted installation.
There were a number of Zoneline units installed in
ducted installations that did not use a GE duct adapter.
The easiest way to determine if the existing duct adapter
is a GE duct adapter is to compare the duct adapter
dimensions to the dimensions above. If the dimensions are
different from the dimensions above or if the duct adapter
is not made of sheet metal, it is not a GE duct adapter.
In such installations, GE recommends the removal of the
old duct adapter and duct extension and the installation
of a RAK6053 duct adapter and a RAK601B duct
extension. Zoneline units installed in installations not
using GE duct adapters and an extension with the same
cross-section dimensions as the duct adapter may not
be covered by the warranty.
*See written warranty for details
FOR THE PERIOD OF
ONE YEAR
From the date of the
original purchase
FIVE YEARS
From the date of the
original purchase
SECOND THROUGH
FIFTH YEAR
From the date of the
original purchase
GE APPLIANCES WILL REPLACE
Any part of the air conditioner which fails due to a defect in materials or workmanship.
During this limited one-year warranty, GE will provide, free of charge, all labor and
related service costs to replace the defective part.
Sealed Refrigerating System – if any part of the Makeup Air Module or Sealed
Refrigerating System (the compressor, condenser, evaporator, and all connecting
tubing) should fail due to a defect in materials or workmanship. During this limited
five-year warranty, GE will provide, free of charge, all labor and related service costs
to replace the defective part.
Fan Motors, Switches, Internal Thermostat, Heater, Heater Protectors, Compressor
Overload, Solenoids, Circuit Boards, Auxiliary Controls, Freeze Sentinel, Frost Controls,
ICR Pump, Capacitors, Varistors and Indoor Blower Bearing, if any of these parts should
fail due to a defect in materials or workmanship. During this additional four-year limited
warranty, the customer will be responsible for any labor and related service costs.
