Working with programs
• Press
p
P appears on the display
•
1
...
9
Enter program number 1 ... 9
With the button
r
and
h
you are able to
change between several program steps.
With
S
the backgauge moves to the indicated
dimension.
With
s
the backgauge stops.
General
LED "S" blinks the basic position will appear.
LED "S" is off the actual dimension appears.
In the program mode the ejection of paper
r
is
not possible. The ejection of paper has to
be programmed.
After each cut press the button
S
the
backgauge moves to the next dimension.
Escape the program mode
• Press
p
P appears on the display.
• Press
s
escape the program mode.
Program buttons
h
and
r
programs
Button
h
= backgauge position rear
Button
r
= backgauge position front
Press
p
and simultaneously
h
(U appears
on the display) or
Press
p
and simultaneously
r
(D appears
on the display)
• Enter the desired dimension (For example:
29,7 cm x 42 cm can be entered for DIN A3)
•
g
Store dimension.
Display in cm or inch
• Press
i
display changes between cm
and inch (see picture left).
Measurements (in cm or inches) for the rear
reference point of the bachgauge are shown
on the top of page 23.
•
Operation
•
