User Manual

- 16 -
IDEAL 4810-95/EP • IDEAL 4850-95/EP • IDEAL 5221-95EP • IDEAL 6550-95EP
C
A
B
D


A
B
Position the main switch to "I" (A). Insert the
key for the control system and move it to the
right (B). Open the safety guard (C). The
machine is now ready for use.
Only IDEAL 4810-95EP, IDEAL 4850-95EP,
IDEAL 5221-95EP, IDEAL 6550-95EP
Press
S
button (D).
Machine will automatically go to the start
position.
IDEAL 4810-95, IDEAL 4850-95,
The measurement is set with the backgauge
crank (A). Proceed to position  generally
from the rear.
The measurement is shown on the scale (B)
just below the indicator and can be read in
mm/cm or inches.
•
Operation
•
