Using the status indicators
Status indicators inform you when a drive is being used or
when a button has been pressed that affects how the
keyboard is used. The status indicators are located below the
touchpad.
Important
If none of the indicators are on, you may need to press FN+F1 to toggle
the status indicators on.
Indicator Icon Description
Wireless
network
(optional)
■
LED on - Wireless IEEE 802.11 radio is
turned on.
■
LED off - Wireless IEEE 802.11 radio is
turned off.
Hard drive
■
LED blinking - Hard drive is being
accessed.
■
LED off - Hard drive is not being
accessed.
Power
■
LED on - Notebook is on.
■
LED blinking - Notebook is in Sleep
mode.
■
LED off - Notebook is off.
Hard drive
Caps lock
Num lock
Wireless network
Power
Battery charge
