9
Right
Component Icon Description
USB ports Plug USB devices (such as a CD or DVD drive,
diskette drive, flash drive, printer, scanner,
camera, keyboard, or mouse) into these ports.
Ethernet jack Plug an Ethernet network cable into this jack.
The other end of the cable can be plugged into
a cable modem, DSL modem, or an Ethernet
network jack. For more information, see
“Connecting to a broadband modem or
network” on page 19.
Modem jack Plug a dial-up modem cable into this jack. For
more information, see “Connecting the dial-up
modem” on page 18.
IEEE 1394 port Plug an IEEE 1394 (also known as Firewire
®
or
i.Link
®
) device (such as a digital camcorder or
MP3 player) into this 4-pin IEEE 1394 port.
Headphone jack Plug amplified speakers or headphones into this
jack. The built-in speakers are turned off when
speakers or headphones are plugged into this
jack.
Microphone jack Plug a microphone into this jack.
Kensington™
lock slot
Secure your notebook to an object by
connecting a Kensington cable lock to this slot.
IEEE 1394 port
Modem
jack
Ethernet
jack
USB ports
Microphone jack
Headphone jack
Kensington lock slot
