CHAPTER 3: Setting Up and Getting Started
24
Status indicators for select models
Indicator Icon Description
Wireless
network
(optional)
■
LED on - Wireless IEEE 802.11 radio is
turned on.
■
LED off - Wireless IEEE 802.11 radio is
turned off.
Caps lock
■
LED on - Caps lock is turned on.
■
LED off - Caps lock is turned off.
Num lock
■
LED on - Numeric keypad is turned on.
■
LED off - Numeric keypad is turned off.
Scroll lock
■
LED on - Scroll lock is turned on.
■
LED off - Scroll lock is turned off.
Hard drive
■
LED blinking - Hard drive is being
accessed.
■
LED off - Hard drive is not being
accessed.
Indicator Icon Description
Wireless
network
(optional)
■
LED on - Wireless IEEE 802.11 radio is
turned on.
■
LED off - Wireless IEEE 802.11 radio is
turned off.
Caps lock
■
LED on - Caps lock is turned on.
■
LED off - Caps lock is turned off.
Num lock
■
LED on - Numeric keypad is turned on.
■
LED off - Numeric keypad is turned off.
A
1
Hard drive
Caps lock
Num lock
Wireless network
Disc drive
A
1
