Mini Central Transmitter:
The Mini Central Transmitter is located in an area that is secure, has adequate air flow, is out of harm’s
way, and accessible for service. Typically, this area is found near the receiving area at the rear of the
store. The Mini Central Transmitter sends the locking signal and unlocking signal through the perimeter
antenna. Once installed and plugged directly in to a 85-264volt AC outlet or Universal Power Supply
(UPS), the Central Transmitter rarely requires service.
Mini Central Transmitter side panel detail:
1. Alarm Buzzer
Alarm will be ON while fault
2. Alarm Reset Switch
Turn OFF the Alarm
3. Power Indicator Light
Green LED to indicate the power is ON
4. Battery Indicator Light
Yellow LED to indicate the battery charging
5. Alarm Indicator Light
Fault Setting
Alarm Buzzer
Alarm Reset Switch
Power Indicator Light
Battery Indicator Light
Alarm Indicator Light
