APPROACH Z82 ® Owner’s Manual
© 2020 Garmin Ltd. or its subsidiaries All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Garmin. Garmin reserves the right to change or improve its products and to make changes in the content of this manual without obligation to notify any person or organization of such changes or improvements. Go to www.garmin.com for current updates and supplemental information concerning the use of this product.
Table of Contents Introduction.....................................................................1 Device Overview ......................................................................... 1 Status LEDs ........................................................................... 1 Charging the Device ................................................................... 1 Turning On the Device ................................................................ 1 Standby Mode .....................................
Introduction WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. Device Overview LED Activity Status Solid red (after holding the power button) The device is turned off. Rapid flashing red (connected to a power source) The device is charging in energy-saving mode. Solid blue and flashing red (connected The device is charging. to a power source) Solid red (connected to a power source) Charging is complete.
Adjusting the Eyepiece The device features an adjustable eyepiece (+/- 4 diopter adjustment). This allows you to focus the screen for your eyesight. Rotate the eyepiece to focus the screen. Bluetooth Connected Features ® This device includes Bluetooth connected features for your compatible mobile device using the Garmin Golf™ app. Scorecard uploads to Garmin Golf: Automatically sends scorecards to the Garmin Golf app when you sync your device.
The compass arrow points to the pin location. A cone appears on the map to help orient you toward the pin. TIP: You can press any key to return to the hole view. Enabling Tournament Mode The tournament mode setting disables the PinPointer and PlaysLike distance features. These features are not allowed during sanctioned tournaments or handicap calculation rounds. 1 Select or to open the menu. 2 Select Settings > Tournament Mode.
Time Format: Sets the device to show time in a 12-hour or 24hour format. Brightness: Sets the brightness level of the backlight. Auto Standby: Adjusts the amount of time before the device automatically goes into standby mode (Standby Mode, page 1). Reset: Allows you to reset user data and settings (Restoring All Default Settings, page 5). Device Information Device Care NOTICE Do not store the device where prolonged exposure to extreme temperatures can occur, because it can cause permanent damage.
2 Disconnect the cable from your computer. Restoring All Default Settings 1 Select Settings > System > Reset. 2 Select an option: • Select Reset Default Settings to reset all of the device settings to the factory default values and save all userentered information. • Select Delete Data and Reset Settings to delete all userentered information and reset all of the device settings to the factory default values. Product Updates On your computer, install Garmin Express (www.garmin.com /express).
Index A accessories 5 apps, smartphone 2 B battery 1 charging 1 storage 4 Bluetooth technology 2 C carabiner clip 4 compass 2 calibrating 3 courses playing 2 selecting 2 customizing the device 3 D device, care 4 display settings 2 distance, measuring 2, 3 G Garmin Express 5 updating software 5 Garmin Golf 2 golf round, ending 3 GPS, signal 4 green view, pin location 2 H holes, changing 3 K keys 1 M maps, symbols 2 measuring a shot 3 menu 1 P pairing, smartphone 2 pin location, green view 2 R resett
support.garmin.
