Installation Instructions

GPSMAP 3006C / 3010C / GPS 17 Installation Guide
+
-
BATTER Y
10-35 V OLTS DC
WIRE
COLOR
GARMIN GSD 20
SOUNDER MODULE
BLA CK
ORANGE
RED
WHITE/BLUE
BLA CK
RED
WHITE/BLUE
WHITE/BRO WN
GARMIN
GPSMAP 3006C/3010C
WHITE/BRO WN
WIRE
COLOR
5A
FUSE
ORANGE
2A
FUSE
T O TRANSDUCER
>
>
>
>
+
-
BATTER Y
10-35 V OLTS DC
WIRE
COLOR
NMEA DEVICE
WITH SONAR OUTPUT/
VHF RADIO WITH
DSC
GROUND
NMEA TX/RX -
PO WER
NMEA RX +
BLA CK
RED
GRAY (PORT 2)
VIOLET (PORT 2)
GARMIN
GPSMAP 3006C/3010C
NMEA TX +
WIRE
TYPE
5A
FUSE
BLUE (PORT 1)
BRO WN (PORT 1)
OR
>
>
>
>
>
>
+
-
BATTER Y
10-35 V OLTS DC
WIRE
COLOR
NMEA DEVICE/
AUTOPILOT
(INPUT ONLY)
GROUND
NMEA RX -
PO WER
NMEA RX +
BLA CK
RED
GARMIN
GPSMAP 3006C/3010C
WIRE
TYPE
5A
FUSE
GRAY (PORT 2)
BLUE (PORT 1)
OR
>
>
>
WIRE
COLOR
GPS 17
GPS/W AAS SENSOR
BLACK (GROUND)
YELLOW (ON)
RED (POWER)
BLUE (DATA IN)
BLACK
ORANGE
RED
GREEN
WHITE
GARMIN
GPSMAP 3006C/3010C
+
-
WHITE (DATA OUT)
WIRE
COLOR
BATTERY
10-35 VOL TS DC
5A
FUSE
1A
FUSE
>
>
>
>
NOTE: If two or more GPSMAP 3006C/3010C
MFDs are installed and networked, the GSD 20
needs to be wired to only one MFD.
