GPSMAP 3006C / 3010C/ GPS 17 Installation Guide Introduction The GPSMAP 3006C/3010C Multi-Function Display (MFD) must be properly installed according to the following instructions to get the best possible performance. To complete the installation, you will need the appropriate fasteners, tools, and mounts listed in each section. These items should be available at most marine dealers. Always wear safety goggles, ear protection, and a dust mark when drilling, cutting, or sanding.
GPSMAP 3006C / 3010C / GPS 17 Installation Guide Flush Mounting the GPSMAP 3006C/3010C: 1. Trim the Flush Mount Template and tape in the desired location. TRIM TEMPLATE ALONG THIS LINE TO AID FITTING 230mm 2. Using the Center Punch, indent the center of each Mounting Hole location. 3. Using an 1/8” (3mm) drill bit, drill the four Mounting Holes. (Drilling the mounting holes before cutting the hole for the unit will allow for an easier installation.
GPSMAP 3006C / 3010C / GPS 17 Installation Guide Installing the GPS 17 The GPS 17 installs on any standard 1” O.D. (Outer Dimension), 14 threads per inch marine mount. The cable can be run externally or, if possible, through the center of the mount. The GPS 17 connects to the 18-pin Power/Data Cable on the GPSMAP 3006C/3010C and provides the GPS/WAAS signal for the unit. If two or more GPSMAP 3006C/3010C units are installed and networked, only one GPS 17 antenna needs to be installed.
GPSMAP 3006C / 3010C / GPS 17 Installation Guide Wiring and Cables The GPSMAP 3006C/3010C comes with an 18-pin Power/NMEA and a 17-pin Marine A/V (Audio/Video). Optional Garmin Marine Network components use specialized Garmin Network Cables. For some installations, it may be necessary to drill 1.25” (31.7mm) holes to route the connector end of the cables. Garmin rubber grommets are provided to cover the installation holes (see below). Wiring and cabling instructions may be found on the following pages.
GPSMAP 3006C / 3010C / GPS 17 Installation Guide Power/NMEA Cable Wiring There are several wiring diagrams on the following pages for your convenience. The first is a simple diagram showing the GPSMAP 3006C/ 3010C MFD (using the 18-pin Power/NMEA wiring harness) and the GPS 17. If two or more GPSMAP 3006C/3010C units are installed and networked, only one GPS 17 antenna needs to be installed.
GPSMAP 3006C / 3010C / GPS 17 Installation Guide GPS 17 GPS/WAAS SENSOR - + GARMIN GPSMAP 3006C/3010C BATTERY 10-35 VOLTS DC WIRE COLOR FUSE 5A > > RED (POWER) BLACK BLACK (GROUND) ORANGE YELLOW (ON) GREEN BLUE (DATA IN) WHITE WHITE (DATA OUT) WIRE COLOR FUSE 5A > > RED BLACK BLACK ORANGE ORANGE WHITE/BLUE WHITE/BLUE WHITE/BROWN WHITE/BROWN FUSE 5A > > > > FUSE 5A > POWER BLACK GROUND > TOTRANSDUCER NOTE: If two or more GPSMAP 3006C/3010C MFDs are installed and networke
GPSMAP 3006C / 3010C / GPS 17 Installation Guide - + DB-9 SERIAL PC CONNECTOR* BATTERY 10-35 VOLTS DC GARMIN GPSMAP 3006C/3010C WIRE COLOR FUSE 5A DB-9 PIN NUMBERS RED PIN 5: GROUND (SG) BLACK BROWN > PIN 3:TRANSMIT (TxD) BLUE > PIN 2: RECEIVE (RxD) * Note: DB-9 connectors normally have pin numbers printed next to each pin.
GPSMAP 3006C / 3010C / GPS 17 Installation Guide Marine A/V (Audio/Video) Cable The GPSMAP 3006C/3010C Marine A/V (Audio/Video) 17-pin cable allows input of NTSC (National Television System Committee) /PAL (Phase Alternate Line) composite video sources, VGA resolution PC monitor output, and future expansion for audio output. Marine A/V inputs are only available on the MFD to which they are attached and will not transmit over the Garmin Marine Network. A pinout of the cable is provided below.
GPSMAP 3006C / 3010C / GPS 17 Installation Guide Garmin Marine Network The Garmin Marine Network is a waterproof Ethernet-based system that allows Multi-Function Displays (MFD) to communicate with sensors and other MFDs over the network. Waterproof RJ-45 connections allow for simple installation and high-speed connectivity. For a simple installation with one MFD and one sensor the two devices can be directly connected with a Garmin Marine Network Cable.
GPSMAP 3006C / 3010C / GPS 17 Installation Guide Final Wiring Connection Once all the wiring is complete, the cables may be attached on the backside of the GPSMAP 3006C/3010C MFD. If the MFD is not being networked, be sure to firmly affix the weather cap over the open connector to limit corrosion of the contacts. The connection ports are labeled on the back of the MFD. Installing the Power/NMEA, Marine A/V, and Network Cables: 1.
