Installation RTCSmp Built-In Module-Line Dual/Quad Cooktops
32 Part # 4532415 Rev 3 (8/19/14)
4.6.3 CHART 3 – Module-Line Full Coil Dual Models
MODU
7000 360FL
(1x)
360 x 360 x 6 mm
(1x)
Frame
for 360 x 360mm
glass
(1x)
IN/MO7000FL
(1x)
344 x 355 mm
2 Rectangular Coils
Each 3.5 kW
(1x)
IN/MO 7000/14000
(1x)
OPERATION
UNIT
CONTROL
UNIT
GLASSFULL COIL,
DUAL MODELS
CABLE KITGENERATOR COIL CARRIER SHEET
(coils + sensors)
MOUNTING FRAME
CAN/BUS
poti/LED
connection
eld1
sensor connection (eld 1)
coil connection
mains
connection
ventilation (fan) cable connection
eld 1 eld 2
mains
connection
eld 1
poti/LED
connection
eld2
CAN/BUS
poti/LED
connection
eld1
coil connec
tion F
ield 2
mains
eld 2
sensor connection (eld 2)
coil connection Field
1
sensor connection (eld 1)
ventilation (fan) cable connection
ventilation (fan) cable connection
(2x)
360 x 360 x 6 mm
(2x)
Frame for 360 x 360mm
glass
(1x)
IN/MO14000FL
(2x)
344 x 355 mm
2 Rectangular Coils
Each 3.5 kW
(2x)
MODU
14000 360FL
(1x)
375 x 650 x 6 mm
MODU
14000 650FL
MODU
14000 720FL
14000 650FL
14000 720FL
Installation
14000 360FL
Installation
7000 360FL
Installation
(1x)
319 x 624 mm
4 Rectangular Coils
Each 3.5 kW
(1x)
360 x 720 x 6 mm
(1x)
Frame for 375 x 650mm
glass
(1x)
Frame
for 360 x 720mm
glass
(1x)
354.5 x 689 mm
4 Rectangular Coils
Each 3.5 kW
coil 1
coil 2
coil 3
coil 4
eld 2eld 1
eld 2
eld 1
mains
eld 1
poti/LED
connection
eld2
CAN/BUS
poti/LED
connection
eld1
coil connection Field 2
mains
connection
eld 2
sensor connection (eld 2)
coil connection Field 1
sensor connection (eld 1)
ventilation (fan)
cable connection
(1x)
IN/MO 7000/14000
(1x)
IN/MO 7000/14000
(1x)
IN/MO 7000/14000
(2x)
(2x)
(1x)
IN/MO14000FL
(1x)
IN/MO14000FL
(1x)
IN/MO7000FL-
360 Cable Kit,
2.5-meter
(Options:
4-meter or
6-meter Kit)
(1x)
IN/MO14000
Cable Kit,
2.5-meter
(Options:
4-meter or
6-meter Kit)
(1x)
IN/MO14000
Cable Kit,
2.5-meter
(Options:
4-meter or
6-meter Kit)
(1x)
IN/MO14000
Cable Kit,
2.5-meter
(Options:
4-meter or
6-meter Kit)
