D GB F NL S FI DK N I E SK Návod na obsluhu Turbotrimmer GR Οδηγίες χρήσης Κουρευτικό πετονιάς RUS Инструкция по эксплуатации Турботриммер SLO Navodilo za uporabo Turbo obrezovalnik HR Upute za uporabu Turbo trimer za travu SRB Uputstvo za rad BIH Turbo trimer-kosilica UA Інструкція з експлуатації Турботример RO Instrucţiuni de utilizare Turbotrimmer TR Kullanma Kılavuzu Turbo Tırpan BG Инструкция за експлоатация Турботример AL Manual përdorimi Kositëse bari turbo EST Kasutusjuhend Turbotrimmer LT
GB GARDENA EasyCut 400/25 Translation of the original German operating instructions. Please read the operating instructions carefully and observe the notes given. Use these operating instructions to familiarise yourself with the product, the proper use and the safety instructions. For safety reasons, children and young people under the age of 16, as well as people not familiar with these operating instructions, may not use this product.
v If the cable of the unit is damaged, the unit must be unplugged from the mains immediately. Check your Trimmer before each use v Always visually inspect your Trimmer before each use. v Check that the ventilation slots are not obstructed in any way. Do not use the trimmer if it is damaged or if its safety devices (pressure switch, safety cover) and / or the filament cassette are damaged or worn. v Never bypass the safety devices. v Inspect the area to be cut before you begin work.
GB Warning! This machine produces an electro magnetical field during operation. This field may under some circumstances interfere with active or passive medical implants. To reduce the risk of serious or fatal injury, we recommend persons Only connect the device to a mains circuit which with medical implants to consult their physician is equipped with a residual current device (RCD) and the medical implant manufacturer before operating this machine.
GB 4. Operation DANGER! Risk of injury if the Turbotrimmer does not switch off when you release the start button. v Never bypass the safety devices or switches (e. g. by tying the start button to the handle). Risk of injury! v Unplug the mains plug of the Turbotrimmer prior to each adjustment of the working position, to the shaft length, additional handle or plant guard! Connecting the trimmer: w e t 1.
GB Setting the trimmer to body height: Setting the shaft length: v Loosen the clamping sleeve i, extend the handle w to the desired shaft length and re-tighten the threaded collar i. 2 The clamping sleeve i must be fastened firmly enough to prevent the shaft from being moved. 1 Setting the additional handle: w v Pull the lock 1 belonging to the additional handle 2, set the additional handle 2 to the desired incline and release the lock 1.
The tip mechanism works when the motor is running. A clean cut is only achieved with the maximum filament length. During first operation, it may be necessary to extend the cutting filament several times. 7 1. Start the trimmer. p 2. Hold the trimmer head 7 parallel to the ground and briefly touch the trimmer head 7 onto a solid surface (avoid constant pressure over extended periods of time).
GB Replacing the filament cassette: v Never use metallic cutting elements or replacement parts and accessories not provided by GARDENA. d f Risk of injury! Only use original GARDENA Filament Cassettes. You can order Replacement Filament Cassettes from your GARDENA dealer or directly from the GARDENA Customer Service. f • f or Art. 9807 EasyCut 400/25: GARDENA Filament Cassette for Turbotrimmers Art. 5307 1. Press in cassette cover d on the two catches f at the same time and remove. g 2.
DANGER! GB 7. Troubleshooting Risk of injury from the cutting filament! v Always unplug the mains plug of the Turbotrimmer before troubleshooting. Pulling the filament out of the filament cassette: If a filament is drawn into the filament cassette you can pull it out again as described below. 1. Remove the filament cassette g as described under 6. Maintenance “Replacing the filament cassette”. g 2. Press together the plastic ring h on the filament cassette g between your thumb and forefinger. 3.
GB 8. Technical Data Turbotrimmer EasyCut 400/25 (Art. No. 9807) Motor power consumption 400 W Mains voltage / mains frequency 230 V / 50 – 60 Hz Filament thickness 1.6 mm Cutting width 250 mm Filament supply 6m Filament feed Tip mechanism Rpm of filament cassette approx. 12,000 rpm Weight approx. 2.9 kg Telescopic adjustment of the turn handle approx.
D Produkthaftung Wir weisen ausdrücklich darauf hin, dass wir nach dem Produkthaftungsgesetz nicht für durch unsere Geräte hervorgerufene Schäden einzustehen haben, sofern diese durch unsachgemäße Reparatur verursacht oder bei einem Teileaustausch nicht unsere originale GARDENA Teile oder von uns freigegebene Teile verwendet wurden und die Reparatur nicht vom GARDENA Service oder dem autorisierten Fachmann durchgeführt wird. Entsprechendes gilt für Ergänzungsteile und Zubehör.
H Termékszavatosság Nyomatékosan utalunk arra a tényre, hogy a természavatossági törvény szerint nem kell jótállást vállalnunk azokra a károkra, amelyeket nem a mi készülékeink okoztak, ha ezeket szakszerűtlen javítás okozta vagy egy alkatrész kicserélésénél nem a mi eredeti GARDENA alkatrészeinket vagy általunk engedélyezett alkatrészeket használtak fel és a javítást nem a GARDENA szerviz vagy egy erre felhatalmazott szakember végezte.
D EG-Konformitätserklärung H EU-Megfelelőségi nyilatkozat GB EU Declaration of Conformity CZ Prohlášení o shodě EU F Certificat de conformité aux directives européennes SK EU-Vyhlásenie o zhode Der Unterzeichnete Husqvarna AB, 561 82 Huskvarna, Sweden bestätigt, dass die nachfolgend bezeichneten Geräte in der von uns in Verkehr gebrachten Ausführung die Anforderungen der harmonisierten EU-Richtlinien, EU-Sicherheitsstandards und produktspezifischen Standards erfüllen.
Bezeichnung der Geräte: Description of the units: Désignation du matériel : Omschrijving van de apparaten: Produktbeskrivning: Beskrivelse af produktet: Laitteiden nimitys: Descrizione dei prodotti: Descripción de la mercancía: Descrição dos aparelhos: Turbotrimmer Turbotrimmer Coupe-bordures Nazwa urządzenia: A készülékek megnevezése: Označení přístrojů: Označenie zariadenia: Ονομασία της συσκευής: Opis naprave: Oznaka uresaja: Descrierea articolelor: Обозначение на уредите: Seadmete nimetus: Prietaisų p
Deutschland / Germany GARDENA GmbH Central Service Hans-Lorenser-Straße 40 D-89079 Ulm Produktfragen: (+ 49) 731 490 - 123 Reparaturen: (+ 49) 731 490 - 290 service@gardena.com China Husqvarna (China) Machinery Manufacturing Co., Ltd. No. 1355, Jia Xin Rd., Ma Lu Zhen, Jia Ding Dist., Shanghai 201801 Phone: (+ 86) 21 59159629 Domestic Sales www.gardena.com.cn Albania COBALT Sh.p.k. Rr. Siri Kodra 1000 Tirana Colombia Husqvarna Colombia S.A. Calle 18 No.
