Installation Guide

1
2
3
4
P L E A S E R E A D C O M P L E T E L Y B E F O R E Y O U B E G I N A S S E M B L Y
Rosedale Arbor
A S S E M B L Y I N S T R U C T I O N S
2
PRELIMINARIES
TOOLS Y OU W I L L N E ED
Phillips screwdriver (electric driver recommended)
Two bags of concrete mix (60#) to anchor the arbor
If you wish to stain or paint your arbor, we recommend that you do so before assembly, it makes the job eas-
ier. Use a high quality exterior stain or paint. Be careful not to cover up guide marks on top of headers.
IF YOU PLAN TO
HANDY TO HAVE
Tape measure
Carpenters Square
WORK AREA
Select an area close to where the arbor will be finally placed. While the assembled unit is not very heavy, it is
awkward to move far and requires two people to do so easily.
The assembly area should be relatively flat and open, at least 8’ square. A lawn, driveway or wide path will be
satisfactory.
It is a good idea to lay out the arbor box on your work surface to protect the arbor from nicks and scratches.
445.35.98 4/27/2007
Trellis Caps (7)
Headers (2)
Braces (4)
Lattice Side Panels (2)
1
2
3
4
HARDWARE
- 2 1/2” Wood screws (30)
- Wood block marked “spacer” (1)
CHECK BOX FOR THESE CONTENTS
Win FREE Arboria Products
Give us feedback about this Arboria product and be entered into a drawing to win more Arboria goods. It’s easy,
go to www.Arboria.com to find the product you purchased, then click on the link to review. Be sure to enter your
email and telephone so that we may contact you if you win. Share a photograph of your product in use for an extra
chance to win.
Visit www.Arboria.com for official sweepstakes rules.
